Lenovo B490 Notebook - Manual (Page 77)

11
12
7
8
9
2
4
10
6
3
5
1
13
14
1 Indonesia D side label 8 Israel label
2 Wireless WAN IMEI barcode label 9 Israel label
3 Brazil Bluetooth label / Bluetooth label for United
States/Canada/Taiwan
10 Malaysia SIRIM label
4 PRC / MTM label / KCC label / Mexico label/MAC label 11 Vodafone label
5 Brazil Wireless LAN label / WLAN label for US/CA/TW 13 Rating label
6 PPT label 12 Windows Certificate of Authentication (COA) label
7 Indonesia WLAN and BT label 14 Rating label
2010 LCD front bezel
For access, remove these FRUs in order:
•
“1010 Battery pack” on page 44
• “1180 LCD unit” on page 66
Chapter 7 . Removing and replacing a FRU 71
