Carefully lift the keyboard until you can see how it’s connected. Hold the keyboard above the computer 4 ,
and then detach the keyboard connector.
5
6
4
When installing: Ensure that the connector is attached firmly.
1100 Keyboard bezel
For access, remove these FRUs in order:
•
“1010 Battery pack” on page 44
• “1020 Bottom slot cover” on page 44
• “1030 Optical drive” on page 45
• “1090 Keyboard” on page 51
54 Hardware Maintenance Manual
