9
SM50EZ
EZ FILL MULTI WELLS,
ITEM STOCK ITEM STOCK
NO. NO. DESCRIPTION NO. NO. DESCRIPTION
1
54561 CONTROL BOX W/ASSY 12.50 ”
2 54503 BEZEL CONTROL 12.50 “
3 56527 THERMOSTAT 36” CAPILLARY
4 56528 KNOB, BLACK
5 63012 INDICATOR LIGHT (56530)
6 54577 ADAPTER, ¼” TUBE TO 3/8 PIPE
7 54578 TUBING, COPPER, ¼
8 55343 90 DEGREE CONDUIT CONNECTOR
9 54511 OCTAL BASE USE WITH 54510
10 54524 BRACKET, SOLENOID VALVE
11 54513 WATER SOLENOID VALVE
12 54510 LIQUID LEVEL CONTROL OCTAL BASE
XXXX LIQUID LEVEL CONTROL OPEN BOARD
13 54512 HOLD DOWN STRAP USE WITH 54510
14 30201 TERMINAL BLOCK
15 54508 BRASS FITTING 1/8 NPT X ¼
COMPRESSION
16 54572 7 QT. ROUND WELL PAN W/COPPER
TUBE
17 50817 PLATE, HEAT DIFFUSER
18 55964 HEATING ELEMENT 208/240V,
500W/660W
19 55696 BRACKET, ELEMENT HOLDER
20 55695 BRACKET, ELEMENT HOLDER
21 89025 10-24 SPEED NUT
22 55992 BOTTOM COVER
23 89059 #10 EXTERNAL LOCK WASHER
24 89061 NUT,HEX 10-24
25 54544 O-RING FOR PROBE HOLDER
26 54543 PROBE HOLDER
27 54546 WASHER ½-20 SS
28 54549 NUT, HEX 1/2-20
29 54545 O-RING FOR SCREW
30 88971
SCREW 8-32 X 1-1/2 SS
31 54548 SPACER, PROBE HOLDER
32 89063 NUT, HEX 8-32
33 56542
PLATE, DIAL-WELLS
34 88961 10-24 HEX NUT, GREEN-GROUND
35 89054 6-32 KEPS NUT
36 88993 10-32 X 3/8 TRUSS HEAD SCREW
37 89073 #8 X 1/2 SHEET METAL SCREW
38 51016 COVER, TERMINAL
39 55342 3/8” CONDUIT
40 55340 ANTI-SHORT BUSHING
41 89120 JIFFY CLIP
42 88889 8 X ½ AB SMS, PHL TRUSS
43 88977 6-32 X 1.0 SLOTTED PAN HEAD
44 55333 WOOD MOUNT KIT SM-50-7
45 55402 EZ LOCK CLIP 4 TAB
HARDWARE NOT SHOWN
56655 DRAIN STRAINER
54532 WIRE SET TWO WELL
54533 WIRE SET THREE WELL
54534 WIRE SET FOUR WELL
54535 WIRE SET FIVE WELL
54536 WIRE SET SIX WELL
