APW Wyott HOT FOOD WARMER - Manual (Page 7)

7
A B C J Overflow D E F G H
SHFWEZ-2D WELL
29.42"
(74.2)
23.44"
(59.5)
27.79"
(70.6)
13.87"
(35.2)
28.5"
(72.4)
22.5"
(57.2)
5.0"
(12.7)
16.50"
(41.9)
n/a
SHFWEZ-3D WELL
43.46"
(110.4)
23.44"
(59.5)
41.83"
(106.2)
27.92"
(70.9)
42.5"
(108.0)
22.5"
(57.2)
5.0"
(12.7)
33.50"
(85.1)
12.50"
SHFWEZ-4D WELL
57.50"
(146.0)
23.44"
(59.5)
55.87"
(141.9)
27.92"
(70.9)
56.5"
(143.5)
22.5"
(57.2)
5.0"
(12.7)
16.50"
(41.9)
n/a
SHFWEZ-5D WELL
71.54"
(181.7)
23.44"
(59.5)
69.92"
(177.6)
41.96"
(106.6)
70.5"
(179.1)
22.5"
(57.2)
5.0"
(12.7)
33.50"
(85.1)
n/a
SHFWEZ-6D WELL
85.59"
(217.4)
23.44"
(59.5)
83.96"
(213.2)
41.96"
(106.6)
84.50"
(214.6)
22.5"
(57.2)
5.0"
(12.7)
33.50"
(85.1)
n/a
Volts Watts Amps 1-Phase Volts Watts
SHFWEZ-2D 208/240 2400/3200 12 / 14 208 3200
SHFWEZ-3D 208/240 3600/4800 18 / 20 208 4800
SHFWEZ-4D 208/240 4800/6400 24 / 27 208 6400
SHFWEZ-5D 208/240 6000/8000 29 / 34 208 8000
SHFWEZ-6D 208/240 7200/9600 35 / 40 208 9600
2. Overflow drain is 1/2" (1.3) OD tube outlet.
3. Main drain is 3/4 female NPT.
1. Water fill is 3/8 (1.0) tubing connection on left
back of left controls
APW EZFILL HOT FOOD WELLS
PART NO'S BEGINNING WITH WHFW
INSTALLATION
1. Follow general installation instructions on
page 3.
2. Make applicable Cut-Out per above table.
Note: Unit is designed for installation in
stainless steel tops. Optional wood mounting
kit available.
3. Apply putty tape to the underside perimeter
of the well rim outer edge.
4. Apply a 1/4" (.6) bead of silicone sealant
adjacent to the putty tape on the well flange.
5. Drop well into opening from the top and
push down until entire parameter of rim is flush
with the counter surface.
6. From below the counter surface insert an 8"
to 10" (20 to 25 cm) flat tip screwdriver into the
locking ring tab slots and twist in a clockwise
motion to lock well in place.
7. Trim excess putty and sealant from around
well rim.
8. Mount control to front panel using hardware.
Maintain 4" (10.2) clearance between well and
front panel.
9. Check nameplate for proper voltage.
Connect power.
10. Connect overflow tube onhot food well to
suitable tubing to handle 212 F water. Run to
open drain.
Note: Electrically connect units to comply
with local and NEC codes.
14
20 / 24
16
47
Stock No.: 56360 Drain Manifold: Fabricated to Unit, Required
ELECTRICAL SPECIFICATIONS
Amps 3-Phase
CLEANING
1. Follow General Cleaning Instructions on page 3.
OPERATION
1. Follow General Operating Instructions on page 3.
NOTE: CUT-OUT SIZES ARE DIFFERENT FROM STANDARD APW HFW'S
16 / 18
20 / 24
23
31
39
21
14
27
27
10 / 12
10 / 12
260 Lbs. (117.9 Kg)
OPTIONS
MODEL
Max Amps 3-Phase
Description: Lever Operated Drain Valve
Amps 1-Phase
Electrical Ratings 1200 EA. @ 208V / 1600 EA. @ 240V Electrical Ratings 1600 EA. @ 208V
48 Lbs. (21.8 Kg)
68 Lbs. (30.8 Kg)
98 Lbs. (44.4 Kg)
118 Lbs. (53.5 Kg)
GENERAL SPECIFICATIONS (APW EZFILL HOT FOOD WELLS)
MODEL
OUTSIDE DIMENSIONS CUT OUT CONTROL CUT OUT SHIP WT.
