21
HFW-2D THROUGH HFW-6D
EZ FILL MULTI WELLS,
ITEM STOCK ITEM STOCK
NO. NO. DESCRIPTION NO. NO. DESCRIPTION
1
54575 WELL PAN W/ASSY (W/COPPER TUBES)
2 55789 SEALANT, PERMAGUM
3 54518 WELL PAN W/ASSY (W/O TUBES)
4 56655 DRAIN STRAINER
5 88971 SCREW 8-32 X 1-1/2 SS
6 54545 O-RING FOR SCREW
7 54543 PROBE HOLDER
8 54544 O-RING FOR PROBE HOLDER
9 89063 NUT, HEX 8-32
10 54548 SPACER, PROBE HOLDER
11 54546 WASHER ½-20 SS
12 54549 NUT, HEX 1/2-20
13 57264 WELL BRACE
14 54577 ADAPTER, ¼” TUBE TO 3/8 PIPE
15 55441 HEATING ELEMENT 208/240V,
1200W/1600W
54051
HEATING ELEMENT 208V/1600W
16 89059 #10 EXTERNAL LOCKWASHER
17 89120 JIFFY CLIP
18 89061 10-24 HEX NUT
19 56039 CAPILLARY COVER FOR T’STATS
20 56506 REFLECTOR PAN
21 89025 10-24 SPEED NUT
22 57252 2 WELL TOP PLATE
57260 3 WELL TOP PLATE
57263 4 WELL TOP PLATE
57290 5 WELL TOP PLATE
57363 6 WELL TOP PLATE
23 89073 #8 X 1/2 SHEET METAL SCREW
24 55308 E-Z LOCK, 6 TAB
25 56050 END COVER
26 56048 CONDUIT BRACE
27 57254 2 WELL FRONT OR BACK COVER
57262 3 WELL FRONT OR BACK COVER
57266 4 WELL FRONT OR BACK COVER
57292 5 WELL FRONT OR BACK COVER
57365 6 WELL FRONT OR BACK COVER
28 60150 1” X 7” X 48” INSULATION HIGH TEMP
29 56388 HOLE COVER
30 54526
2 WELL BOTTOM COVER
54538 3 WELL BOTTOM COVER
54539 4 WELL BOTTOM COVER
54540 5 WELL BOTTOM COVER
54541 6 WELL BOTTOM COVER
31 54524 BRACKET, SOLENOID VALVE
32 54508 BRASS FITTING 1/8 NPT X ¼
COMPRESSION
33 54504 CONTROL BOX W/ASSY 12.50 ”
54522 CONTROL BOX W/ASSY 16.50 “
54529 CONTROL BOX W/ASSY 33.50 “
34 54512 HOLD DOWN STRAP USE WITH 54510
35 54510 LIQUID LEVEL CONTROL OCTAL BASE
XXXX LIQUID LEVEL CONTROL OPEN BOARD
36 88977 6-32 X 1.0 SLOTTED PAN HEAD
37 54511 OCTAL BASE USE WITH 54510
38 54503 BEZEL CONTROL 12.50 “
54521 BEZEL CONTROL 16.50 ”
54529 BEZEL CONTROL 33.50 “
39 88889 8 X ½ AB SMS, PHL TRUSS
40 56536 INDICATOR LIGHT (56530)
41 56505 KNOB, THERMOSTAT
42 89054 6-32 KEPS NUT
43 54513 WATER SOLENOID VALVE
44 30201 TERMINAL BLOCK
45 56540 THERMOSTAT 72” CAPILLARY
46 56527 THERMOSTAT 36” CAPILLARY
47 55099 ¾ ” CONDUIT 24” LONG
48 55058 90 DEGREE CONDUIT CONNECTOR
49 88993 10-32 X 3/8 TRUSS HEAD SCREW
50 55059 ANTI-SHORT BUSHING
51 87822 WASHER REDUCING 1 X 3/4
52 89184 7/8” HOLE BUSHING
53 57258 2 WELL DRAIN MANIFOLD
57273 3 WELL DRAIN MANIFOLD
57267 4 WELL DRAIN MANIFOLD
57293 5 WELL DRAIN MANIFOLD
57366 6 WELL DRAIN MANIFOLD
HARDWARE NOT SHOWN
88961 10-24 HEX NUT, GREEN-GROUND
54578 TUBING, COPPER
56542 DIAL PLATE
54532 WIRE SET TWO WELL
54533 WIRE SET THREE WELL
54534 WIRE SET FOUR WELL
54535 WIRE SET FIVE WELL
54536 WIRE SET SIX WELL
