Nilfisk-ALTO RS 501 - Manual (Page 98)

ENGLISH USER MANUAL
10 33015501(3)2008-02 A RS 501
Diesel engine data (*) Values
Make Lombardini
Type LDW1603 B2
Cylinders 3
Maximum speed 2,600 rpm
Maximum working speed 2,200 rpm
Maximum power at 2,600 rpm 25.0 kW
Idle speed 900 rpm
Displacement 1,649 cm 3
Consumption while operating at 2,200 rpm (recommended speed) 5.0 L/h
Consumption while operating at 2,600 rpm (maximum speed) 5.9 L/h
Engine coolant 50% of AGIP antifreeze and 50% of water (**)
Engine oil AGIP Sigma Turbo 15W/40 (***)
(*) For other diesel engine data/values, see the relevant Manual.
(**) See the coolant technical data and reference data tables below.
SPECIFICATIONS REFERENCE DATA
Boiling point °C 170 CUNA NC 956-16 97
Boiling point in solution with 50% water °C 110 FF.SS cat. 002/132
Freezing point in solution with 50% water °C -38 ASTM D 1384
Colour /
Turquoise
blue
Density at 15°C kg/l 1.13
(***) See the engine oil technical data and reference data tables below.
SPECIFICATIONS REFERENCE DATA
SAE QUALITY / 15W40 ACEA E3-96
Viscosity at 100°C mm²/s 13.7 API Service CG-4/SG
Viscosity at 40°C mm²/s 100 CCMC D5, PD-2
Viscosity at -15°C mm²/s 3,300 US Department of the Army MIL-L-2104 E
Viscosity index / 138 US Department of the Army MIL-L-46152 E
Flash point COC °C 230 MACK EO-L
Pour point °C -27 MAN M 3275
Density at 15°C kg/l 0.885 Mercedes Benz 228.3
VOLVO VDS2
MTU typ 2
Refuelling data Values
Fuel tank capacity 30 litres
Hydraulic system oil tank capacity 60.6 litres
Hydraulic system oil capacity 58 litres
Electrical system data Values
System voltage 12 V
Starting battery 12 V – 80 Ah
