USER MANUAL ENGLISH
RS 501 33015501(3)2008-02 A 9
TECHNICAL DATA
Dimensions and weights Values
Machine length (broom bristles not included) 3,065 mm
Machine width (broom bristles not included) 1,315 mm
Distance between front and rear wheels 1,475 mm
Front wheel base 930 mm
Rear wheel base 840 mm
Machine height 1,997 mm
Minimum distance from the ground (skirts not included) 90 mm
Maximum front working angle 18°
Maximum dumping height 1,460 mm
Front tyres R165/70 R14C 89R
Rear tyres R165/70 R14C 89R
Tyre pressure 3.75 Bar
Side broom diameter 720 mm
Total machine weight, in running condition (without operator) 1,500 kg
Performance data Values
Maximum forward speed (for transport only) 18 km/h
Maximum working speed 12 km/h
Maximum reverse speed 8 km/h
Gradeability at full load 22% (30% optional)
Minimum inner turning radius 2,460 mm
Maximum side broom speed 80 rpm
Collection system Suction
Cleaning width 1,600 mm
Filtering system Metallic net
Sound pressure level at workstation (ISO/EN3744) at maximum working speed 82 dB(A)
Certifi ed sound power (2000/14/EC) at maximum working speed 108 dB(A)
Measured sound power (ISO/EN3744) at maximum working speed 106 dB(A)
Hopper capacity 500 litres
Hopper maximum load 380 kg
Dust control By water
Dust control system tank total capacity (no. 2) 240 litres
Lighting and signalling system Road type
Transmission Hydrostatic servoassisted
Steering system On the rear axle, power assisted
Brake Hydraulic
Parking brake Mechanic
Controls Hydraulic
