Remove the upper case
Make sure the following FRUs (CRUs) have been removed:
“Remove the keyboard” on page 29
Step 1. Pry the two rubbers out of their recesses.
Figure 6. Pry rubbers out of recesses
Note: The rubbers are connected to the Chromebook through rubber pins and cannot be
completely detached.
Step 2. Remove the two screws 1 under the rubbers.
Step 3. Remove the four screws 2 .
a
a
b
b
b
b
Figure 7. Remove 6 screws
Step 4. Turn over the Chromebook and open the LCD cover.
Step 5. Open the touch pad socket 3 and pull out the cable 4 .
Chapter 4 . Removing a FRU or CRU 31
