5
C. Contents
1. 1 x 7 ’’ LCD Monitor & DVD Player Combo
2. 1 x 7
” LCD Monitor
3. 2 x AC to DC Adapter
4. 1 x Remote Control with battery (CR2025)
5. 1 x Instruction Manual
6. 1 x AV Adapter Cable (One to Three Female)
7. 1 x AV Adapter Cable (One to Three Male)
8. 1 x Y Type DC Power Adapter
9. 1 x Rechargeable Battery
10. 1 x Mounting Bag With Straps for the Monitor
11. 1 x Carry Bag With Straps
D. Powering and installation
1. Powering the system indoors (Refer to Figure 1)
Plug one end of the AC to DC adapter into the DC 9V jack on the
right side of the main unit, then plug the other end into a 120V
AC power outlet.
The monitor can also be powered in the same manner.
2. Powering the system in a car (refer to Figure 2)
Plug one end of the DC power adapter into the DC 9V jack
on the main unit, then plug the other end into the vehicle power
socket.
Figure 1
Single Monitor Main Unit
