Audiovox D1718ES - Manual (Page 34)

34
8. SPECIFICATIONS
Compatible DISC: DVD/CD/MP3
Signal system: NTSC
Panel size: 7 inch
DVD video format: Horizontal 720 pixel, vertical 480 pixel (NTSC)
Frequency response: 20 Hz to 20 kHz
Video output: 1 Vp-p/75 Ohm, unbalanced
Audio output: 1.4V
rms
/10kOhm
Audio S/N: Better than 60 dB
Dynamic range : Better than 85 dB
Laser: Semiconductor Laser, Wave Length: 650 nm/795 nm
Power source: DC 9V
Power consumption: 12 W
Operating temperature: 5~35
°C
Weight : 0.78 kg
Dimensions (W x D x H):7.87 X 5.92 X1.44inches
200 x 150.5 x 36.5mm
Battery Type: Ni-Mh
NTSC
7 Inches
480 x 234
DC 9V-12V
6W, 0.5 Amp
41~104 º F (5~40ºC)
10-75%
4~140 º F (-20~60ºC)
8.0 ” x 0.5” x 6.0”
(204 x 151 x 12 mm)
0.72 lbs (0.327kg)
Single Monitor
Color System:
Screen Size:
Resolution:
Power Supply:
Power Consumption:
Operating Temperature:
Operating Humidity:
Storage Temperature:
Dimensions (W x D x H):
Weight:
