Page 19

1
Status indicator
3
Media card reader slot
2
Built-in microphone
1
Status indicator
The status indicators show the current status of your computer. For more information, refer to “Status
indicators” on page 6.
2
Built-in microphone
The built-in microphone captures sound and voice when it is used with an application program capable
of handling audio.
3
Media card reader slot
For more information, refer to “Using the media card reader” on page 18.
Bottom view
4
2
1
3
Figure 5. Lenovo B480 and B580 bottom view
1
Battery latch (manual)
3
Battery latch (spring loaded)
2
Battery
4
Bottom slot cover
1
Battery latch (manual)
Keeps the battery secured in place.
2
Battery
Use your computer with battery power whenever ac power is unavailable. For more information, refer to
“Using the ac power adapter and the battery pack” on page 13.
Chapter 1
.
Getting to know your computer
5
