7. Close the adapter latch to retain the adapter.
8. Reinstall the PCI riser assembly into the system board.
9. Go to “Completing the parts replacement” on page 30.
Replacing the fan assembly
Attention
Do not open your computer or attempt any repair before reading the “Important safety
information” in the Safety and Warranty Guide that was included with your computer. To
obtain a copy of the Safety and Warranty Guide, go to the Support Web site at
http://www.lenovo.com/support.
This section provides instructions on how to replace the fan assembly.
1. Open the computer cover. See “Opening the cover” on page 5.
2. Pivot the drive bay assembly upward to gain access to the fan assembly 1 .
3. Disconnect the fan assembly cables from the system board. See “Identifying
parts on the system board” on page 4.
Chapter 2. Replacing hardware 25
