• “1020 Bottom slot cover” on page 44
• “1050 Hard disk drive” on page 46
• “1030 Optical drive” on page 45
• “1040 Memory modules” on page 45
• “1060 PCI Express Mini Card for wireless LAN” on page 48
• “1080 Backup battery” on page 50
• “1090 Keyboard” on page 51
• “1100 Keyboard bezel” on page 53
• “1160 System board assembly and USB board” on page 61
• “1190 LCD unit” on page 67
Removal steps of LCD front bezel
Remove the screws 1 .
1
1
Step Screw (quantity) Color Torque
1 M2 × 3.5 mm, flat-head, nylon-coated (2) Black 1.6 kgf-cm
