Chapter 5. Lenovo V480 and V480c
This chapter presents the following product-specific service references and parts information:
• “Specifications” on page 37
• “Status indicators” on page 38
• “Fn key combinations” on page 39
Specifications
This topic lists the physical features for the Lenovo V480 and V480c models.
Processor
• Windows 7: To view the system properties of your computer, click Start, right-click Computer; then
click Properties.
• Windows 8: From the desktop, move the cursor to the top-right or bottom-right corner of the screen to
display the charms. Then click Settings ➙ PC info.
Memory
• Double data rate 3 (DDR3) synchronous dynamic random access memory (SDRAM)
Storage device
• 2.5-inch (7 mm height or 9.5 mm height) hard disk drive
• mSATA solid-state drive (on some models)
Note: If the computer is equipped with both a hard disk drive and an mSATA solid-state drive, do not use the
mSATA solid-state drive as a bootable device. The mSATA solid-state drive is used for “cache” function only.
Display
• Size: 14.0 inches (356 mm)
• Resolution:
– LCD: 1366-by-768
– External monitor: Maximum 2048-by-1536
• Integrated camera (on some models)
Keyboard
• 6-row Lenovo keyboard
• Recovery button
Interface
• Combo audio jack
• Two USB 2.0 connectors
• Two USB 3.0 connectors
• RJ45 Ethernet connector
• HDMI port
© Copyright Lenovo 2012 37
