Installing

the

cover

To

install

the

cover,

place

it

into

position

and

slide

it

forward.

Connecting

the

cables

The

following

illustrations

show

the

locations

of

the

input

and

output

connectors

on

the

front

and

rear

of

the

server.

Front

1

USB

1

connector

2

USB

2

connector

Rear

You

1

Power-cord

connector

5

Ethernet

1

connector

2

Systems-management

connector

6

Ethernet

2

connector

3

USB

3

connector

7

Video

connector

4

USB

4

connector

8

Serial

connector

must

turn

off

the

server

before

you

connect

or

disconnect

cables.

See

the

documentation

that

comes

with

any

external

devices

for

additional

cabling

instructions.

It

might

be

easier

for

you

to

route

cables

before

you

connect

the

devices

to

the

server.

Chapter

2.

Installing

optional

devices

23
