Lenovo M5400 Touch Notebook User Manual
Page 61
57
Lenovo B5400/M5400/M5400 Touch
Figure 12. Removal steps of fan assembly and heat sink assembly (continued)
Lift the fan assembly and heat sink assembly in the direction shown by arrow
3
.
Be careful not to damage the connector.
Attention: Do not handle the heat sink assembly roughly. Improper handling
can cause distortion or deformation and imperfect contact with components.
