b. Pull up the release latch 1 on the front end of the right slide rail. Keep the release latch in the
raised position and pull out the slide rail lock 2 .
Figure 6. Unlocking the slide rail lock
c. Position the front part of the right slide rail to the mounting flange. Make sure that the front end and
rear end of the right slide rail are at the same horizontal level. Push the right slide rail 1 until the
front end of the right slide rail is firmly secured to the mounting flange. Push the slide rail lock 2
back horizontally until it is locked into place.
Figure 7. Securing the front end of the right slide rail to the mounting flange
7
