Lenovo H535 Desktop User Manual
Page 30
MM ff oo pp ww pp !! II 66 44 66
1. Power connector
7. USB 2.0 connectors
2. Voltage selection switch (selected models only)
8. Audio connectors
3. USB 2.0 connectors
9. Expansion card slots (some models are equipped with
graphics card, USB 3.0 or TV tuner card)
4. HDMI connector (selected models only)
10. Ethernet connector
5. On-board VGA connector
11. Wi-Fi antenna (selected models only)
6. USB 3.0 connectors
24
Lenovo H505/520/535Hardware Maintenance Manual
