Lenovo H535 Desktop User Manual
Page 29
MM ff oo pp ww pp !! II 66 33 11
1. Power connector
6. USB connectors
2. Voltage selection switch (selected models only)
7. Audio connectors
3. USB connectors
8. Expansion card slots (some models are equipped with
graphics card, USB 3.0 or TV tuner card)
4. HDMI connector (selected models only)
9. Ethernet connector
5. On-board VGA connector
10. Wi-Fi antenna (selected models only)
Chapter 7
.
Locating connectors, controls and components
23
