AXIS 243SA - Technical specifications
Connectors
• Analog composite video, PAL/NTSC auto-sensing input
• 1 BNC input,
• 1 BNC output (loopthrough) or Y/C video input
• RJ-45 for Ethernet 10BaseT/100BaseTX
• Terminal block for 4 alarm inputs, 4 outputs, RS-485 half duplex port and alternative
power connection
• D-sub for RS-232 port
• 3.5 mm jack for Mic or Line mono input
• 3.5 mm jack for Line mono output
Casing
• Metal casing. Standalone, stackable or with brackets for wall or cage mount
Processors and memory
• CPU: ETRAX 100LX
• Video processing and compression: ARTPEC-2
• RAM: 32 MB
• Flash: 8 MB
• Battery backed up real-time clock
Power
• 7 - 20 V DC, max 8 W
Operating conditions
• 5 - 50 ºC (41 - 122 ºF)
• Humidity 20 - 80% RH (non-condensing)
Installation, management
and maintenance
• AXIS Camera Management tool on CD and web-based configuration
• Configuration of backup and restore
• Firmware upgrades over HTTP or FTP, firmware available at www.axis.com
Video access from Web
browser
• Camera live view for up to 20 clients,
• Video recording to file (ASF),
• Sequence tour for up to 20 PTZ presets or external Axis video sources
• Customizable HTML pages
Minimum Web browsing
requirements
• Pentium III CPU 500 MHz or higher, or equivalent AMD,128 MB RAM, DirectX 9
compatible graphics board, Direct Draw
• Windows XP, 2000, Internet Explorer 6.x or later
• For other operating systems and browsers see www.axis.com/techsup
System integration
support
• Open API for software integration, including VAPIX® from Axis Communications*,
AXIS Media Control SDK*, event trigger data in video stream and access to serial
port peripherals over HTTP
• Quality of Service (QoS) Layer 3, DiffServ Model
• Watchdog
• Embedded Linux operating system
* Available at www.axis.com
Supported protocols
• IPv4/v6, HTTP, HTTPS, SSL/TLS*, TCP, QoS, SNMPv1/v2c/v3 (MIB-II), RTSP, RTP, UDP,
IGMP, RTCP, SMTP, FTP, ICMP, DHCP, UPnP, Bonjour, ARP, DNS, DynDNS, SOCKS,
IEEE802.1X. More information on protocol usage available at www.axis.com
*This product includes software developed by the Open SSL Project for use in the
Open SSL Tool kit (www.openssl.org)
Item
Specification
