36 AXIS 243SA - Event configuration
Note:
Using the motion detection feature may decrease overall performance in the video server.
How to configure Motion Detection
This example describes how to configure motion detection:
1. Click Motion Det ection in the Event Configuration menu.
2. Click the Configure Included Windows radio button.
3. Click New.
4. Enter a descriptive name of your choice under Windows name.
5. Adjust the size (drag the bottom right-hand corner) and position (click on the text
at the top and drag to the desired position).
6. Adjust the Object size, History and Sensitivity profile sliders (see table below for
details). Any detected motion within an active window is then indicated by red
peaks in the Activity window (the active window has a red frame).
7. Click Save.
If there are parts of the Include window that you wish to exclude, click the
Configure Excluded Windows radio button and perform steps 3-7 above.
