ABOUT YOUR PNP300/350 2
PNP300/350
Pop ‘N Plug Slim Interconnect Box
The PNP300/350 is designed for installation in a
conference room table, podium, or anywhere
computer audio, video, and communications
connections are needed. The Pop ‘N Plug Slim
provides a means of connecting audio, video,
control, and computer video sources into a
presentation system. It is ideal for use together with
ALTINEX computer video interfaces.
The PNP300/350 Pop ‘N Plug Slim interconnect
“pops up” into a raised position to provide access to
connectors. When not in use, it is lowered into the
tabletop providing a clean, smooth finish. The
PNP300/350 uses a tower-type construction with a
pneumatic suspension and a mechanical latching
mechanism.
The PNP300 has one input plate on the front panel
of the unit. The standard plate offers input
connections for the following: AC power (NEMA
5-15R), computer video (15-pin HD), composite
video (RCA), stereo audio (RCAx2), computer
audio (3.5 mm stereo), modem (RJ-11), RS-232
(9-pin D-sub), and network (RJ-45). All signals pass
from the interface plate, through standard cables,
and terminate in the mating connector for easy
connection to the audiovisual system.
The PNP350 Interconnect Box has one input plate
on the front panel of the unit. The standard plate
offers 2 AC power outlets and 6 RJ-45 network
snap-in connectors. All interface connections
include pass-through connectors and cables.
The Pop ‘N Plug Slim Interconnect Boxes are
designed for use with tabletops ranging from
0.25 in (6 mm) to 3.75 in (95 mm) thick.
TECHNICAL SPECIFICATIONS 3
Specifications are subject to change.
See
www.altinex.com for up-to-date information.
FEATURES/
DESCRIPTION INTERFACE
CONNECTION
UNDER TABLE
CONNECTION
PNP300 Connectors
AC (NEMA) 5-15R (1) 5-15P (1)
Computer video 15- pin HD F (1) 15- pin HD M (1)
Computer audio 3.5 mm F (1) 3.5 mm M (1)
Composite video RCA F (1) RCA M (1)
Stereo audio RCA F (2) RCA M (2)
Modem RJ-11 F (1) RJ-11 M (1)
Network RJ-45 F (1) RJ-45 M (1)
RS-232 Control DB9 F (1) DB9 M (1)
PNP350 Connectors
AC (NEMA) 5-15R (2) 5-15P (2)
Network RJ-45 F (6) RJ-45 M (6)
Table 1. PNP300/350 General
MECHANICAL PNP300/350
Minimum Table Thickness 0.25 in (6 mm)
Maximum Table Thickness 3.75 in (95 mm)
Length (bezel) 10.03 in (255 mm)
Width (bezel) 3.39 in (86 mm)
Height (opened, above table) 2.19 in (56 mm)
Depth (below table top) 6.14 in (156 mm)
Finish Black
T
°
Operating (T
°
Max) 10
°
C-40
°
C (50
°
C)
Humidity 90
%
non-condensing
Table 2. PNP300/350 Mechanical
ELECTRICAL PNP300/350
PNP300 90-140 VAC, 5A Max.
PNP350 (each outlet) 90-140 VAC, 5A Max.
Table 3. PNP300/350 Electrical
