2
Model O411
Dimensions Machine with crate
width 19-1/2’’ (49,5 cm) 27’’ (68,6 cm)
height 67’’ (170,2 cm) 78’’ (198,1 cm)
depth 38-1/4’’ (97,2 cm) 48’’ (121,9 cm)
Weight 450 lbs (204,1 kg) 650 lbs (294,8 kg)
Electrical 1 Phase, 208-240 VAC, 60Hz
running amps 15A
connection type NEMA6-20P power cord provided
Compressor 13,000 Btu/hr Scroll™ Compressor
Drive Motor 3/4 hp
Air Flow Air cooled units require 3” (7,6 cm) air space at the back.
Plumbing Fittings Water cooled units require 1/2” N.P.T. water and drain fi ttings.
Hopper Volume 8 gallons (30,29 liters)
Freezing Cylinder
Volume
1 gallon (3,79 liters)
1.2 SPECIFICATIONS
