PPC-155T User Manual 8
Chapter 2 System Setup
2.1 A Quick Tour of the Panel PC
Before starting to set up the panel PC, take a moment to become familiar with the
locations and purposes of controls, drives, connectors and ports, which are illustrated
in the figures below.
When placed upright on the desktop, the front panel of the panel PC appears as
shown in Figure 2-1:
Figure 2.1 Front panel of PPC-155T
When viewed from the left side of the panel PC, the CD-ROM drive and PCMCIA
expansion sockets are visible, as shown in Fig. 2-2:
Figure 2.2 Left side view of the panel PC
Light sensor
LAN HDD
Power
Hole for Panel mount
PCMCIA
Speaker
CDR/DVD
HDD Cover
