PFW 6875
Installation Instructions Page 15
flay
Maintenance and Servicing
1) Push evenly in the front of the PFW 6875 to release
the single latch spring lock(Figure 1).
2) Slowly pull the front of the PFW 6875 to extend the
scissor arms (Figure 2).
3) Loosen the locking safety screws on both mounting
brackets.
4) Tilt up the bottom of the flat-panel, then set their
kickstands against the bottom tubing of the mount
(Figures 2 & 3).
You can now reach behind the flat-panel for
maintenance and servicing or replacement. After
servicing, make sure the spring lock is locked again
in the mount's closed position.
Figure 3
Figure 1
Figure 2
Single Latch
Spring Lock
