NOTES:
• Series available in round configuration only.
• When testing 9123 Series, it may take up to 16 seconds longer for smoke alarm to go in or out of alarm mode.
• It is recommended that 9000/9003 Series smoke alarm be tested weekly.
• Refer to Technical Bulletin 002 for Easy Wash TM on site washing instructions
• 9120/9220 units produce a non-temporal audible alarm and are therefore not intended for locations where the desired action of the occupant(s) is evacuation.
• 9123/9223 units produce a temporal 3 audible alarm. Per NFPA 72, the American National Standard Audible Emergency Evacuation Signal as defined in ANSI S3.41,
is required whenever the intended response is to evacuate the building.
9000 (9120/9220) Series - Continuous Piezo Sounder
9003 (9123/9223) Series - Temporal 3 Evacuation Piezo Sounder
Model
Number
Part
Number Voltage
Integral
135 o F
Thermal
Isolated
135 o F
Thermal
Tandem
Up To
12 Units
Tandem
Up To
6 Units
Form A/C
Contacts
9120 917-0001-002 120VAC
9120T 917-0002-002 120VAC
9120H 917-0003-002 120VAC
9120F 917-0004-002 120VAC
9120TF 917-0009-002 120VAC
9120HF 917-0005-002 120VAC
9220 917-0026-002 220VAC
9220T 917-0027-002 220VAC
9220H 917-0028-002 220VAC
9220F 917-0029-002 220VAC
9220TF 917-0031-002 220VAC
9220HF 917-0030-002 220VAC
Model
Number
Part
Number Voltage
Integral
135 o F
Thermal
Isolated
135 o F
Thermal
Tandem
Up To
12 Units
Tandem
Up To
6 Units
Form A/C
Contacts
9123 917-0012-002 120VAC
9123T 917-0013-002 120VAC
9123H 917-0014-002 120VAC
9123F 917-0015-002 120VAC
9123TF 917-0017-002 120VAC
9123HF 917-0016-002 120VAC
9223 917-0032-002 220VAC
9223T 917-0033-002 220VAC
9223H 917-0034-002 220VAC
9223F 917-0035-002 220VAC
9223TF 917-0037-002 220VAC
9223HF 917-0036-002 220VAC
