3-14
Mainboard Setup
▍
MS-9298
Mainboard Setup
▍
MS-9298
J
umper
Clear CMOS Jumper: JCLR_CMOS1
There is a CMOS RAM onboard that has a power supply from an external battery
to keep the data of system configuration. With the CMOS RAM, the system can
automatically boot OS every time it is turned on. If you want to clear the system
configuration, set the jumper to clear data.
Important
You can clear CMOS by shorting 2-3 pin while the system is off. Then return to
1-2 pin position. Avoid clearing the CMOS while the system is on; it will damage
the mainboard.
BIOS Recovery Jumper: JRECOVERY1
Users can short connect pin#2-3 to recover the system BIOS with a Recovery
Floppy. When the system is done with the job, the buzzer will beep to remind the
user to set the jumper to its normal state (pin#1-2 short connected).
Normal or Clear
by BMC (default)
1
Clear Data
1
JCLR_CMOS1
1
Normal (default)
1
BIOS recovery
1
JRECOVERY1
1
