Hardware Setup
▍
MS-96D7
2-17
Hardware Setup
▍
MS-96D7
BIOS Recovery Jumper: JBOOT1
Users can short connect pn#2-3 to recover the system BIOS. When the system
s done wth the job, the buzzer wll beep to remnd users to set the jumper to ts
normal state (pn#1-2 short connected).
BIOS Write Protect Jumper: JBWP1
This jumper is used to enable/disable the BIOS flash. When you intend to update
the BIOS code, short connect pin#2-3 first. Under normal operation, we suggest
that you disable the BIOS flash by short connecting pin#1-2 to protect the system
BIOS from vrus nfecton.
Recovery Normal
JBOOT1
1 1 1
Normal Wrte Protecton
JBWP1
1 1 1
