MSI H61MA-E35 (B3) - Manual (Page 28)

2-14
Hardware Setup MS-7740
Chapter 2
Front USB Connector: JUSB1~2
This connector, compliant with Intel ® I/O Connectivity Design Guide, is ideal for con-
necting high-speed USB interface peripherals such as USB HDD, digital cameras, MP3
players, printers, modems and the like.
1 1 5 V
1.V
C
C
3.U
SB
0-
10
.N
C
5.U
SB
0+
7.G
ro
un
d
9.N
o
Pin
8.G
ro
un
d
6.U
SB
1+
4.U
SB
1-
2.V
C
C
* The MB layout in this figure is for reference only.
USB Bracket (optional)
Important
Note that the pins of VCC and GND must be connected correctly to avoid possible
damage.
Front Panel Audio Connector: JAUD1
This connector allows you to connect the front panel audio and is compliant with Intel ®
Front Panel I/O Connectivity Design Guide.
1.M
IC
L
3.M
IC
R
10.
He
ad
Ph
one
De
tec
tion
5.H
ead
Ph
one
R
7.S
EN
SE
_S
EN
D
9.H
ead
Ph
one
L
8.N
o P
in
6.M
IC
De
tec
tion
4.N
C 2.G
rou
nd
