Chapter 1
1-5 Getting Started
Back Panel
Connectors
1x PS/2 keyboard/ mouse combo port
2x USB 2.0 ports
4x USB 3.0 ports
1x VGA port
1x DVI-D port
1x HDMI port
1x DisplayPort
1x Optical S/PDIF-Out connector
1x LAN (RJ45) port
6x OFC audio jacks
■
■
■
■
■
■
■
■
■
■
Internal
Connectors
1x 24-pin ATX main power connector
1x 8-pin ATX 12V power connector
8x SATA 6Gb/s connectors
3x USB 2.0 connectors (supports additional 6 USB 2.0 ports)
1x USB 3.0 connector (supports additional 2 USB 3.0 ports)
1x 4-pin CPU fan connector
2x 4-pin system fan connectors
1x Front panel audio connector
2x System panel connectors
1x Chassis Intrusion connector
1x TPM module connector
1x Serial port connector
1x Clear CMOS jumper
1x OC Genie button
1x Power button
1x Reset button
1x OC Genie mode switch
1x Slow mode booting switch
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
I/O
Controller
Fintek 71878 Controller Chip ■
Hardware
Monitor
CPU/System temperature detection
CPU/System fan speed detection
CPU/System fan speed control
■
■
■
BIOS
Features
64 Mb flash
UEFI AMI BIOS
ACPI 5.0, PnP 1.0a, SM BIOS 2.7, DMI 2.0
Multi-language
■
■
■
■
Special
Features
Military Class 4
Military Class Essentials
OC Genie 4
Click BIOS 4
AMD CrossFire
AMD Dual Graphics
4K UHD Support
4 Display Outputs
PCI Express Gen 3
USB 3.0
SATA 6Gb/s
Command Center
Fast Boot
Live Update 5
M-Flash
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
