Chapter 1
1-4 Getting Started
Motherboard Specifications
CPU
Support
AMD Socket FM2+/ FM2 A-Series/Athlon™ Processors ■
Chipset AMD A88X ■
Memory
Support
4x DDR3 memory slots supporting up to 32GB
Supports DDR3 2400 (OC)/ 2133/ 1866/ 1600/ 1333 MHz
Dual channel memory architecture
Supports non-ECC, un-buffered memory
Supports AMD Memory Profile (AMP)
Supports Extreme Memory Profile (XMP)
■
■
■
■
■
■
Expansion
Slots
2x PCIe x16 slots
PCI_E1 supports up to PCIe 3.0 x16 speed*
PCI_E4 supports up to PCIe 3.0 x8 speed*
2x PCIe 2.0 x1 slots
* Only FM2+ processors can support PCIe 3.0
■
-
-
■
Graphics 1x VGA port, supporting a maximum resolution of 1920x1200 @
60Hz, 24bpp
1x DVI-D port, supporting the maximum resolutions of
2560x1600@60Hz, 24bpp/ 1920x1200 @ 60Hz, 24bpp
1x HDMI port, supporting the maximum resolutions of
4096x2160@24Hz, 36bpp*/ 3840x2160@30Hz, 36bpp*/
1920x1200@120Hz, 36bpp and 1920x1200@60Hz, 36bpp
1x DisplayPort, supporting a maximum resolution of
4096x2160@24HZ, 24bpp**
* Only support when using an FM2+ APU.
** The DisplayPort does not support "Hot-plug".
■
■
■
■
Multi-GPU
Support
Supports 2-Way AMD ® CrossFire TM Technology*
* Supports Windows 7 and Windows 8.
■
Storage AMD ® A88X Chipset
8x SATA 6Gb/s ports
Supports RAID 0, RAID1, RAID5 and RAID 10
■
-
-
USB AMD ® A88X Chipset
4x USB 3.0 ports (2 ports on the back panel, 2 ports available
through the internal USB connectors)
8x USB 2.0 ports (2 ports on the back panel, 6 ports available
through the internal USB connectors)
VIA VL806 Chipset
2x USB 3.0 ports on the back panel*
* These USB 3.0 ports do not support M-Flash recovery function.
■
-
-
■
-
Audio Realtek ® ALC1150 Codec
7.1-Channel High Definition Audio
Supports S/PDIF output
■
-
-
LAN Killer E2205 Gigabit LAN controller*
1x LAN port on the backpanel
* The Killer Network Manager is only available for Windows 7 and Windows 8 currently. The
supported drivers for other operating systems would be available on the website if provided
by vendor.
■
-
