Chapter 1
1-10 Getting Started
▶HDMI Port
®
The High-Definition Multimedia Interface (HDMI) is an all-digital audio-video interface
that is capable of transmitting uncompressed streams. HDMI supports all types of TV
formats, including standard, enhanced, or high-definition video, plus multi-channel
digital audio on a single cable.
▶DisplayPort
DisplayPort is a digital display interface standard. This connector is used to connect a
monitor with DisplayPort inputs.
Important
This platform supports dual-display function.
HDMI+DisplayPort
Extend mode
(Extend the desktop to the second and third monitor)
◯
Clone mode
(Monitors have the same screen)
◯
▶Audio Ports
These connectors are used for audio devices. The color of the jack refers to the
function of the connector.
■ Blue-Line in: Used for connecting external audio outputting devices.
■ Green- Line out: Used as a connector for speakers or headphone.
■ Pink- Mic: Used as a connector for a microphone.
■ Black- RS-Out: Rear surround sound line out in 4/ 5.1/ 7.1 channel mode.
■ Orange- CS-Out: Center/ subwoofer line out in 5.1/ 7.1 channel mode.
■ Gray- SS-Out: Side surround sound line out in 7.1 channel mode.
