H2TU-C for Litespan Using Narrowband/Wideband Pairs
PROVISIONING OPTIONS / LOOPBACK FUNCTIONS
Upon initial insertion of the Litespan H2TU-C into the Litespan system, the H2TU-C is provisioned
with the configuration data stored in the shelf controller. The H2TU-C should be pre-provisioned as
indicated under “Pre-Configuration Value” in the table below. The loopback function codes are shown
at right.
H2TU-C
Options
Corresponding
Litespan Parameter
H2TU-C
Available Setting
Corresponding
Litespan Setting
Pre-Configurable
Value
Line Code
LINECDE
AMI
B8ZS
AMI
B8ZS
B8ZS
Framing
1
FMT
SF
ESF
Unframed
Auto
SF
ESF
UNFR
AUTO
AUTO
NIU Loopback
NIDLPBK
Disabled
Enabled
NO
YES
YES
Loopback
Timeout
1
LBKTMO
0
20 Minutes
60 Minutes
120 Minutes
0
20
60
120
120
DS1 TX Level
AT
0
–7.5 dB
–15 dB
0.0
–7.5
–15
0.0
New England
Loopback
1,2
LPBKACTR
Disabled
Enabled
0000000000000000
0000000000000001
0000000000000000
Latching
Loopback
FT1MODE
T1
FT1
NO
YES
NO
Span Power
LP
Disabled
Enabled
SINK
SOURCE
SOURCE
Customer Loss
Indicator
3
LPBKDEACTCDE
AIS
AIS/CI
Loopback
0000000000000000
0000000000000001
0000000000000010
0000000000000001
PRM Setting
LPBKACTC
None
SPRM
NPRM
Auto (Both)
0000000000000000
0000000000000001
0000000000000010
0000000000000011
0000000000000001
Network Keep
Alive
NTWKKPALV
Disabled
Enabled
NO
YES
NO
1. Some settings may not be available at the H2TU-R.
2. This option is only available if the H2TU-R P/N 1221026L1, 1222026L1, 1223026L1 is used in the circuit.
3. This option is not available if the H2TU-R P/N 1221026L1, 1222026L1, 1223026L1 is used in the circuit.
Function/Code
Response
1 in 3
(1)
(100)
Loop down everything
1 in 6 (100000)
(1)
If armed, Loops back at the H2TU-R toward the network.
4 in 7 (1111000)
Loops back data from network toward network in the H2TU-C
6 in 7 (1111110)
Loops back data from customer toward customer in H2TU-C
1111 1111 0001 1110
Loops back data from network toward network at H2TU-C (FF1E HEX)
0011 1111 0001 1110
Loopback data from customer toward customer at H2TU-C (3F1E HEX)
Arm/ 11000 (known as
2-in-5 pattern)
(1)
Loops the H2TU-R toward the network and arms the H2TU-C. No AIS or errors are sent. When
sent from the customer, this code arms all modules.
Arm/ FF48
(1)
(1111 1111 0100 1000)
This pattern is sent on ESF FDL. When sent from network, all modules are armed and the
H2TU-R is looped back toward network. This code has no functionality when sent from the
customer.
Disarm/ 11100
(1)
(known
as 3-in-5 pattern)
All modules are removed from the armed state and looped down when the 11100 pattern is
received. The
LBK
LEDs turn off on all modules.
Disarm/ FF24
(1)
(1111 1111 0010 0100)
This pattern is sent on ESF facility data link, and disarms and/or loops down all modules.
H2TU-C Network Loop up
/ D3D3
(1, 2)
(1101 0011 1101 0011)
If the modules have been armed and no modules are in loopback
(5)
, the H2TU-C loops up
toward the network, 2 seconds of AIS (all 1s) are sent, 5 seconds of data pass, and then 231 bit
errors are injected into the DSX-1 signal. As long as the pattern continues to be sent, 231
errors are injected every 20 seconds. When the pattern is removed, the module remains in
loopback. If the pattern is reinstated, the injection of 231 bit errors resumes at 20-second
intervals.
H2TU-R Address 20 for
extended demarc / C754
(1)
(1100 0111 0101 0100)
When sent from the network, an H2TU-R network loopback is activated and a 200-bit error
confirmation is sent. 2 seconds of AIS (all 1s) is sent, 5 seconds of data pass, and then 200 bit
errors are injected into the DSX-1 signal. As long as the pattern continues to be sent, 200
errors are injected every 20 seconds. The HDSL2 office unit does not block transmission of far-
end NIU loopback from the customer premise (H2TU-R).
Loop down / 9393
(1, 3)
(1001 0011 1001 0011)
All modules currently in loopback loop down, but remain in the armed state.
Query Loopback / D5D5
(1, 2)
(1101 0101 1101 0101)
If the modules are armed and the H2TU-C or H2TU-R are in network loopback, errors are
injected into the DSX-1 signal upon detection of the query loopback pattern. As long as the
pattern continues to be sent, errors are injected again every 20 seconds. The number of errors
injected each time depends on which unit is in loopback. 231 errors are injected if the H2TU-C
is in network loopback and 20 at a time if the H2TU-R is in network loopback.
Query Loop Parameters/
DBDB
(2)
(1101 1011 1101 1011)
If the units are armed and the H2TU-C is in network loopback, errors are injected into the
DSX-1 signal upon detection of the query loop parameters pattern. As long as a pattern contin-
ues to be sent, errors are injected again every 20 seconds. The number of errors injected each
time depends on the current status of signal quality and pulse attenuation parameters on each
loop.
111 errors are injected if all HDSL2 receiver points (H2TU-C, and H2TU-R) indicate pulse
attenuation is 30 dB or lower and signal quality (margin) is 6 dB or higher.
11 errors at a time are injected if any of the receiver points indicate pulse attenuation is greater
than 30 dB and/or signal quality (margin) is less than 6 dB.
Loopback Time Out Over-
ride / D5D6
(1, 2, 4)
(1101 0101 1101 0110)
If the units are armed and this pattern is sent, the loopback time out is disabled. The time out
option is updated to NONE on the PROVISIONING menu of the H2TU-R screens (viewable
through the RS-232 port). As long as the units remain armed, the time out remains disabled.
When the units are disarmed, the loopback time out returns to the value it had before the
D5D6 code was sent.
Span Power Disable /
6767
(1, 2, 4)
(0110 0111 0110 0111)
If the units are armed and this pattern is sent, the H2TU-C deactivate the span power supply,
removing power to the H2TU-R. As long as the pattern continues to be sent, the span power
supply remains disabled. When the pattern is discontinued, the H2TU-C reactivates its span
power supply, returning power to the remote unit. All units retrain and return to the disarmed
and unlooped state.
Note: All codes listed above must be sent for a minimum of 5 seconds in order for them to be detected and acted upon.
1. The H2TU-C and H2TU-R individually detect and act upon in-band loopback control codes. Depending on which list
number of H2TU-R is used with the Litespan H2TU-C, some of these control codes may not cause action (such as loop
up, error injection, etc.) at the H2TU-R. Refer to the H2TU-R documentation for supported control codes.
2. Modules must be armed with 11000b or FF48h for this code to function.
3. In order to behave like a NIU, the H2TU-R can not loop down from the network side with 9393h.
4. This code can be detected only if the modules are armed OR if any loopbacks are active.
5. If NIU is enabled, then the H2TU-R can be in network loopback when the H2TU-C or H2R loop up codes are sent.
