Cirrus Logic CRD4299-1 AVR User Manual
Crystalclear™ ac '97 amr reference design
Preliminary Product Information
This document contains information for a new product.
Cirrus Logic reserves the right to modify this product without notice.
1
Copyright
Cirrus Logic, Inc. 1999
(All Rights Reserved)
P.O. Box 17847, Austin, Texas 78760
(512) 445 7222 FAX: (512) 445 7581
http://www.cirrus.com
OCT ‘99
DS319RD1A1
CRD4299-1 AMR
CrystalClear™ AC '97 AMR Reference Design
Features
l
AMR Audio Codec add-in card designed to
meet the Intel
®
Audio/Modem Riser
Specification
l
High quality, low cost, 2-layer, single sided
adapter board
l
CS4299 SoundFusion
®
Audio Codec ’97
l
Complete suite of Analog and Digital I/O
connections:
- Line In, Line Out, Mic In, Modem Audio
connection, CD Audio In, Video In, Aux In,
Headphone Out and Optical Digital Out
l
Meets or exceeds Microsoft’s PC 97, PC 98,
and PC 99, both required and advanced,
audio performance requirements.
Description
The CRD4299-1 AMR add-in board reference design
showcases Cirrus Logic’s Crystal Audio AC ’97 CS4299
SoundFusion, and is Audio/Modem Riser Specifica-
tion[2], compliant. The CRD4299-1 AMR card is 2.7"
high by 3.6" long.
The CRD4299-1 AMR reference design includes a cus-
tomer ready manufacturing kit. Included in the kit are a
full set of schematic design files (OrCAD
®
7.2 format),
PCB job files (PADS
®
ASCII), PCB artwork files
(Gerber) , bracket drawings, and bill of materials. The
design is production ready as is, or can be easily
modified to incorporate specific OEM changes. Docu-
mentation source files are available to assist the OEM to
quickly provide an accurate end user manual.
ORDERING INFO CRD4299-1 AMR
CS4299
Document Outline
- CRD4299-1 AMR: CrystalClear™ AC '97 AMR Reference Design
- Features
- Description
- TABLE OF CONTENTS
- LIST OF FIGURES
- LIST OF TABLES
- Contacting Cirrus Logic Support
- 1. GENERAL INFORMATION
- 2. REFERENCE DESIGN FEATURES
- 3. SCHEMATIC DESCRIPTION
- 4. GROUNDING AND LAYOUT
- 5. AUDIO PERFORMANCE EVALUATION
- Table 1. Reference Designators
- Table 2. Microphone Support Specifications
- Table 3. Full Duplex Specifications
- Table 4. Analog Mixer, Line In to Line Out Specifications
- Table 5. Analog Mixer, Mic In to Line Out Specifications
- 5.1 Plots
- Figure 1. Full Duplex (A-D-PC-D-A): Line In/Out Frequency Response
- Figure 2. Full Duplex (A-D-PC-D-A): Line In/Out Dynamic Range
- Figure 3. Full Duplex (A-D-PC-D-A): Line In/Out THD+N vs. Frequency
- Figure 4. Analog Mixer (A-A): Line In/Out Frequency Response
- Figure 5. Analog Mixer (A-A): Line In/Out Dynamic Range
- Figure 6. Analog Mixer (A-A): Line In/Out THD+N vs. Frequency
- Figure 7. Analog Mixer (A-A): Mic In/Line Out Frequency Response
- Figure 8. Analog Mixer (A-A): Mic In/Line Out Dynamic Range
- Figure 9. Analog Mixer (A-A): Mic In/Line Out THD+N vs. Frequency
- Figure 10. Analog Mixer (A-A): Line In/Out Crosstalk vs. Frequency
- 6. REFERENCES
- 7. SCHEMATIC, LAYOUT, AND BRACKET DRAWINGS
- 8. BILL OF MATERIALS
