CS42518

INT

Interrupt

(Output) - The CS42518 will generate an interrupt condition as per the Interrupt Mask register.

See

“Interrupts” on page 39

for more details.

RST

Reset

(Input) - The device enters a low power mode and all internal registers are reset to their default

settings when low.

AINR-
AINR+

13
14

Differential Right Channel Analog Input

(Input) - Signals are presented differentially to the delta-sigma

modulators via the AINR+/- pins.

AINL+
AINL-

15
16

Differential Left Channel Analog Input

(Input) - Signals are presented differentially to the delta-sigma

modulators via the AINL+/- pins.

Quiescent Voltage

(Output) - Filter connection for internal quiescent reference voltage.

FILT+

Positive Voltage Reference

(Output) - Positive reference voltage for the internal sampling circuits.

REFGND

Reference Ground

(Input) - Ground reference for the internal sampling circuits.

AOUTA1 +,-
AOUTB1 +,-
AOUTA2 +,-
AOUTB2 +,-
AOUTA3 +,-
AOUTB3 +,-
AOUTA4 +,-
AOUTB4 +,-

36,37
35,34
32,33
31,30
28,29
27,26
22,23
21,20

Differential Analog Output

(Output) - The full-scale differential analog output level is specified in the

Analog Characteristics specification table.

VA
VARX

24
41

Analog Power

(Input) - Positive power supply for the analog section.

AGND

25
40

Analog Ground

(Input) - Ground reference. Should be connected to analog ground.

MUTEC

Mute Control

(Output) - The Mute Control pin outputs high impedance following an initial power-on con-

dition or whenever the PDN bit is set to a ‘1’, forcing the codec into power-down mode. The signal will
remain in a high impedance state as long as the part is in power-down mode. The Mute Control pin goes
to the selected “active” state during reset, muting, or if the master clock to left/right clock frequency ratio
is incorrect. This pin is intended to be used as a control for external mute circuits to prevent the clicks
and pops that can occur in any single supply system. The use of external mute circuits are not manda-
tory but may be desired for designs requiring the absolute minimum in extraneous clicks and pops.

LPFLT

PLL Loop Filter

(Output) - An RC network should be connected between this pin and ground.

RXP7/GPO7
RXP6/GPO6
RXP5/GPO5
RXP4/GPO4
RXP3/GPO3
RXP2/GPO2
RXP1/GPO1

42
43
44
45
46
47
48

S/PDIF Receiver Input/ General Purpose Output

(Input/Output) - Receiver inputs for S/PDIF encoded

data. The CS42518 has an internal 8:2 multiplexer to select the active receiver port, according to the
Receiver Mode Control 2 register. These pins can also be configured as general purpose output pins,
ADC Overflow indicators or Mute Control outputs according to the RXP/General Purpose Pin Control
registers.

RXP0

S/PDIF Receiver Input

(Input) - Dedicated receiver input for S/PDIF encoded data.

TXP

S/PDIF Transmitter Output

(Output) - S/PDIF encoded data output, mapped directly from one of the

receiver inputs as indicated by the Receiver Mode Control 2 register.

VLS

Serial Port Interface Power

(Input) - Determines the required signal level for the serial port interfaces.

SAI_SDOUT

Serial Audio Interface Serial Data Output

(Output) - Output for two’s complement serial audio PCM

data from the S/PDIF incoming stream. This pin can also be configured to transmit the output of the inter-
nal and external ADCs.

RMCK

Recovered Master Clock

(Output) - Recovered master clock output from the External Clock Reference

(OMCK, pin 59) or the PLL which is locked to the incoming S/PDIF stream or CX_LRCK.

CX_SDOUT

CODEC Serial Data Output

(Output) - Output for two’s complement serial audio data from the internal

and external ADCs.

ADCIN1
ADCIN2

58
57

External ADC Serial Input

(Input) - The CS42518 provides for up to two external stereo analog to digital

converter inputs to provide a maximum of six channels on one serial data output line when the CS42518
is placed in One-Line Mode.
