CS3003
DS735F3 5
1.3 Absolute Maximum Ratings
2. TYPICAL PERFORMANCE PLOTS
Parameter Min Typ Max Unit
Supply Voltage [(V+) – (V-)] 2.7 - 5.5 V
Input Voltage (V-) – 0.3 - (V+) + 0.3 V
Storage Temperature Range -65 - +150 ºC
1
10
100
1000
0.01 0.1 1 10
Frequency (Hz)
Figure 1. Noise vs Frequency (Measured)
-20
0
20
40
60
80
100
120
140
160
180
Gain
(dB)
-135
-90
-45
0
45
90
135
180
225
270
Phase
(Deg.)
Frequency (Hz)
0.001 0.1 10 1k 100k 10M 0.01 1 100 10k 1M
-180
Figure 3. Gain & Phase vs. Frequency (2.7 V)
0.8
0.85
0.9
0.95
1
1.05
1.1
1.15
1.2
2.5 3 3.5 4 4.5 5 5.5 6
Supply Voltage (V)
Supply
C
u
rre
nt
(m
A
)
Figure 5. Supply Current vs. Supply Voltage
Figure 2. 0.01 Hz to 10 Hz Noise
-200
-150
-100
-50
0
50
100
150
200
0 1 2 3 4 5 6 7 8 9 10
Time (sec)
-20
0
20
40
60
80
100
120
140
160
180
Frequency (Hz)
Gain
(dB)
-180
-135
-90
-45
0
45
90
135
180
225
270
Phase
(Deg.)
0.001 0.1 10 1k 100k 10M 0.01 1 100 10k 1M
Figure 4. Gain & Phase vs. Frequency (5 V)
0.5
0.75
1.0
1.25
-40 -15 10 35 60 85 110 125
Temperature (°C)
Supply
C
urre
nt
(m
A
)
5V
2.7V
Figure 6. Supply Current vs. Temperature
