CS2300-01

PS846A4

2

1. PIN DESCRIPTIONS

See the CS2300-OTP datasheet for additional pin de-
scription information.

2. SPECIFICATIONS

Please see the CS2300-OTP datasheet for package in-
formation, device characteristics, and specifications ex-
cept where noted due to specific programming options.

3. OPERATIONAL INFORMATION

Complete operational information can be found in the
CS2300-OTP datasheet. Specific operational details
dictated by the programming of the CS2300-01 are in-
cluded below.

The PLL clock output is forced to 0 when the PLL is
unlocked, both upon loss of the CLK_IN signal or
briefly when switching mode pin configurations.

The minimum loop filter bandwidth once locked is
1 Hz.

4. CONFIGURATION INFORMATION

The CS2300-01 has been factory pre-programmed with a unique configuration. The following table outlines the spe-
cific configuration profile which can be compared to the CS2300-OTP datasheet for detailed functional descriptions.

5. ORDERING INFORMATION

Pin Name

#

Pin Description

VD

1

Digital Power

GND

2

Ground

CLK_OUT

3

PLL Clock Output

LOCK

4

Active Low PLL Lock Indicator

CLK_IN

5

Clock Input

FILTP
FILTN

6
7

LCO Filter Connections

OUT_EN

8

Active Low CLK_OUT Enable Input

M1
M0

9

10

Mode Selection Inputs

OTP Modal and Global Configuration Parameters Form

Mode 0

Mode 1

Mode 2

Mode 3

Ratio 0 (dec)

1

2

4

8

Ratio 0 (hex)

00:10:00:00

00:20:00:00

00:40:00:00

00:80:00:00

RModSel1

0

0

0

0

RModSel0

0

0

0

0

AuxOutSrc1

1

1

1

1

AuxOutSrc0

1

1

1

1

AutoRMod

0

0

0

0

Global Configuration Set

ClkSkipEn

AuxLockCfg

ClkOutUnl

LFRatioCfg

M2Cfg2

M2Cfg1

M2Cfg0

0

0

0

1

0

0

0

ClkIn_BW2

ClkIn_BW1

ClkIn_BW0

0

0

0

Product

Description

Package

Pb-Free

Grade

Temp Range Container

Order#

CS2300-01

Clocking Device

10L-MSOP

Yes

Commercial

-10° to +70°C

Rail

CS230001-CZZ

Tape and

Reel

CS230001-CZZR

CDK-2000

Evaluation Platform

-

Yes

-

-

-

CDK-2000-LCO
