Page 5
CRD1630-10W
DS1004RD2
5
3. BILL OF MATERIALS
Reference
Description
Part Number
Manufacturer
BR1
IC RECT BRIDGE 0.5A 600V 4SOIC
MB6S
Fairchild
C1
CAP CER 150PF 50V 5% NP0 0603
ECJ-1VC1H151J
Panasonic-ECG
C2
CAP CER 1.0UF 25V X7R 10% 0603
TMK107B7105KA-T
Taiyo Yuden
C3, C15, C17
CAP CER 0.1UF 25V X7R 10% 0603
CC0603KRX7R8BB103
Yageo
C4
CAP FILM 33nF 250V 10% RADIAL
ECQ-E2333KF
Panasonic-ECG
C5
CAP CER 1UF 50V 10% X5R 0603
UMK107BJ105KA-T
Taiyo Yuden
C6
CAP FILM 0.15uF 250V 10% RADIAL
ECQ-E2154KF
Panasonic-ECG
C7
CAP FILM 68nF 250V 10% RADIAL
ECQ-E2683KF
Panasonic-ECG
C8
CAP CER 2200PF 250V 20% RADIAL
CS11-E2GA222MYNS
TDK Corporation
C9
CAP CER 100PF 50V X7R 10% 0603
C1608X7R1H101K
TDK Corporation
C10, C12
CAP CER 4.7UF 25V 10% X7R 0805
TMK212AB7475KG-T
Taiyo Yuden
C11
CAP ALUM 22UF 35V 20% RADIAL
ECA-1VM220
Panasonic-ECG
C13, C18
NOPOP
C14, C16
CAP CER 47PF 50V C0G 5% 0603
C1608C0G1H470J
TDK Corporation
C19
CAP ALUM 22UF 250V 20% RADIAL
250PX22MEFC10X16
Rubycon
C20
CAP ALUM 68UF 16V 20% RADIAL
EEU-FM1C680
Panasonic-ECG
C21
CAP ALUM 47UF 25V 20% RADIAL
EEU-FM1E470
Panasonic-ECG
C24
CAP CER 470PF 50V 10% X7R 0603
C1608X7R1H471K
TDK Corporation
D1, D6, D8, D10
DIODE SWITCH 100V 400MW SOD123
1N4148W-7-F
Diodes, Inc.
D2
DIODE SCHOTTKY 40V 120MA SOD-323
RB751V40,115
NXP
D3
DIODE SCHOTTKY 30V 200MA SOT23
BAT54S-TP
Micro Commercial
D5
DIODE SCHOTTKY 30V 1A SMA
MBRA130LT3G
Fairchild
D7
DIODE 350V 200MW SOD323-W
BAV3004WS-7
Diodes Inc.
D9
DIODE ZENER 5.1V 500MW SOD80C
BZV55-C5V1,115
NXP
D11
DIODE ULTRA FAST 400V 1A SMA
US1G-13-F
Diodes Inc.
D15
DIODE SCHOTTKY 90V 1A SMB
MBRS190T3G
ON Semi
FH1
FUSE PICE FAST 1A AXIAL
0251001.MXL
Littelfuse Inc
L3
MANHATTAN_11W_BOOST_EE10
KEE-QM-GC-0535
Kunshan Eagerness Electronics
L4
10mH Inductor
RL-5480-3-10000
Renco
Q1
MOSFET N-CH 600V 1A DPAK
STD1NK60T4
ST Microelectronics
Q2
MOSFET N-CH 500V 380MA TO-92
FQN1N50CTA
Fairchild
Q3
MOSFET N-CH 600V 1.7A TO252-3
IPD60R3K3C6
Infineon
Q4
MOSFET N-CH 60V 200MA SOT23-3
2N7002P,215
NXP Semiconductors
Q5
MOSFET N-CH 60V 1.2A SOT23-3
ZXMN6A07FTA
Diodes/Zetex
R1
RES 1.5K OHM 1/4W 5% 1206 SMD
ERJ-8GEYJ152V
Panasonic-ECG
R2, R12
RES 10K OHM 1/10W 5% 0603 SMD
ERJ-3GEYJ103V
Panasonic-ECG
R3
RES 6.81K OHM 1/10W 1% 0603 SMD
ERJ-3EKF6811V
Panasonic-ECG
R4, R5, R10
RES 47 OHM 1/10W 5% 0603 SMD
ERJ-3GEYJ470V
Panasonic-ECG
R6
RES 22.0K OHM 1/10W 1% 0603 SMD
ERJ-3EKF2202V
Panasonic-ECG
R7
RES 4.7K OHM 1/4W 5% 0603 SMD
CRCW06034K70JNEAHP
Vishay
R8, R16
RES 47K OHM 1/10W 5% 0603 SMD
ERJ-3GEYJ473V
Panasonic-ECG
R9, R11
RES 470 OHM METAL FILM 2W 5%
PR02000204700JR500
Vishay
R13, R14, R17, R18
RES 750K OHM 1/8W 5% 0805 SMD
ERJ-6GEYJ754V
Panasonic-ECG
R19
100K OHM 5% THERMISTOR NTC
NCP18WF104E03RB
Murata
R20
RES 2K OHM 1W 5% METAL OXIDE
ERG-1SJ202
Panasonic-ECG
R21
RES 3.4OHM 1/4W 1% 1206 SMD
RC1206FR-073R4L
Yageo
R22
RES 33.0K OHM 1/10W 1% 0603 SMD
ERJ-3EKF3302V
Panasonic-ECG
R23
RES 2.7K OHM 1/10W 5% 0603 SMD
ERJ-3GEYJ272V
Panasonic-ECG
R24
RES 1.0K OHM 1/10W 5% 0603 SMD
ERJ-3GEYJ102V
Panasonic-ECG
R25
RES 7.5 OHM 1/10W 5% 0603 SMD
ERJ-3GEYJ7R5V
Panasonic-ECG
R26
RES 0.0 OHM 1/10W 0603 SMD
ERJ-3GEY0R00V
Panasonic-ECG
R29
RES 14.0K OHM 1/10W 1% 0603 SMD
ERJ-3EKF1402V
Panasonic-ECG
R33
RES 75 OHM 1/10W 5% 0603 SMD
ERJ-3GEYJ750V
Panasonic-ECG
TX1
MANHATTAN_10W_FLYBACK
KEE-QM-GC-0536
Kunshan Eagerness Electronics
U1
CS1630
CS1630-FSZ
Cirrus Logic
U2
SINGLE POSITIVE-EDGE-
TRIGGERED D-TYPE FLIP-FLOP
SN74LVC1G80DBVR
TI
Z2
DIODE ZENER 16V 1W DO-41
1N4745A,113
NXP
Figure 2. Bill of Materials
