CRD1616-8W
DS1003RD4 5
3. BILL OF MATERIALS
Item Rev DescripƟon Qty Reference Designator MFG MFG P/N
1 DIODE RECT 400V 0.8A NPB MINIDIP 1 BR1 DIODES INC HD04-T
2 CAP 47uF ±20% 35V AL ELEC NPb RAD 1 C1 KEMET ESK476M035AC3AA
3 CAP 0.047uF ±5%LS 400V MTL NPb RAD 1 C2 KEMET PHE426KJ5470JR05
4 A CAP 2200pF ±10% 2KV CERAMIC NPb TH 1 C3 MURATA DEBB33D222KA2B
5 CAP 680uF ±20% 35V AL ELEC NPb RAD 1 C4 PANASONIC EEUFR1V681
6 CAP 1uF ±10% 25V X7R CER NPb 0603 2 C5 C6 TDK CGA3E1X7R1E105K
7 CAP 0.022uF ±5%LS 400V MTL NPb RAD 1 C11 KEMET PHE426KJ5220JR05
8 CAP 0.068uF ±5%LS 400V MTL NPb RAD 1 C13 PANASONIC ECQE4683RJF
9 DIODE RECT 600V 1A 50mA NPb DO-41 1 D1 DIODES INC 1N4005
10 DIODE HS SWT 100V 300mA NPb SOD323 1 D2 MICRO COMMERCIAL 1N4148WX-TP
11 DIODE FAST 600V 1A NPb DO-41 1 D3 ST STTH1R06
12 DIODE ULT FAST 600V 1A NPb SMA 1 D4 ST MICROELECTRONICS STTH1L06A
13 DIODE FAST SW 100V 400mW NPb SOD123 1 D5 DIODES INC 1N4148W-7-F
14 DIODE SCHOTTKY 350mA 30V NPb SOD323 1 D6 MICRO COMMERCIAL SD103BWS-TP
15 DIODE SKY RECT 100V 1A NPb DO-214AC 1 D7 MCC SS110-TP
16 NO POP PAD H40 P64 NPb TH 4 E1 E2 E5 E6 NO POP NP-PAD-H40P64
17 IND 10mH ±10% 34OHM NPb 350DIA TH 1 L1 COILCRAFT RFB0807-103L
18 XFMR 4.0mH ±10% 10KHz NPb TH 1 L4 KUNSHAN EAGERNESS EE13-CL03
19 THERM 100K OHM ±5% 0.10mA NPb 0603 1 NTC MURATA NCP18WF104J03RB
20 TRAN MSFET nCH 60V 360mA NPb SOT-23 1 Q1 NXP 2N7002P,215
21 TRAN MOSFET nCH 1.3A 600V NPb DPAK 1 Q2 ALPHA & OMEGA AOD1N60
22 TRAN MOSFET nCH 2.5A 800V NPb IPAK 1 Q4 ST MICROELECTRONICS STD3NK80Z-1
23 RES 47 OHM 1/10W ±1% NPb 0603 2 R2 R19 PANASONIC ERJ3EKF47R0V
24 RES 4.7K OHM 2W 5% MTL FILM NPb AXL 1 R3 YAGEO FMP200JR-52-4K7
25 RES 1k OHM 1/2W ±5% CARFL NPb AXL 1 R4 STACKPOLE ELECTRONICS CFM12JT1K00
26 RES 30K OHM 1/8W ±0.1% NPb 0805 1 R5 PANASONIC ERA-6YEB303V
27 RES 4.42 OHM 1/8W ±1% NPb 0805 FLM 1 R6 YAGEO RC0805FR-074R42L
28 RES 1.50M OHM 1/4W ±1% NPb 1206 2 R7 R8 PANASONIC ERJ8ENF1504V
29 RES 56 OHM 1W 5% MTL FILM NPb AXL 1 R9 YAGEO FMP100JR-52-56R
30 RES 69.8k OHM 1/10W ±1% NPb 0603 1 R10 DALE CRCW060369K8FKEA
31 RES 100 OHM 2W 5% FUSIBLE WW NPb AX 1 R12 YAGEO FKN2WSJR-73-100R
32 RES 51.1k OHM 1/10W±1% NPb 0603 FLM 1 R13 DALE CRCW060351K1FKEA
33 RES 270 OHM 2W ±5% MTL FLM NPb AXL 1 R15 PANASONIC ERG2SJ271
34 RES 53.6k OHM 1/10W±1% NPb0603 FILM 1 R17 DALE CRCW060353K6FKEA
35 RES 15k OHM 1/10W ±1% 0603 FILM 1 R18 DALE CRCW060315K0FKEA
36 RES 3k OHM 1/10W ±5% NPb 0603 FILM 1 R23 DALE CRCW06033K00JNEA
37 A0 IC CRUS TRIAC DIM PFC 230V NPb SO16 1 U1 CIRRUS LOGIC CS1616-FSZ/A0
38 VARISTOR 275V 80pF 23J 7mm NPb RAD 1 VR1 LITTELFUSE V275LT4P
39 DIODE ZENER 500mW 16V NPb SOD123F 1 Z1 NXP NZH16C,115
40 DIODE TVS 300V 600W NPb DO-204AC 1 Z2 LITTELFUSE P6KE350A
Figure 2. Bill of Materials
