Page 5
AN400
5
3. BILL OF MATERIALS
Ref
Description
Manufacturer Part Number
Manufacturer
BR1
DIODE RECT 200V 0.8A NPB MINIDIP
HD02-T
DIODES INC
C1
CAP FILM 0.047UF 250VDC RADIAL
B32529C3473K
EPCOS Inc
C2
CAP FILM 0.068UF 250VDC RADIAL
B32529C3683J
EPCOS Inc
C3
CAP FILM 0.15UF 250VDC RADIAL
B32529C3154J289
EPCOS Inc
C4
CAP CER 0.1UF 25V 10% X7R 0603
GRM188R71E104KA01D
Murata Electronics North America
C5
CAP CER 0.047UF 25V 10% X7R 0603
C1608X7R1E473K
TDK Corporation
C7
CAP ALUM 33UF 35V 20% RADIAL
ECA-1VHG330
Panasonic Electronic Components
C8
CAP ALUM 470UF 50V 20% RADIAL
UHE1H471MHD6
Nichicon
C9, C10
CAP CER 56PF 50V 5% NPO 0603
CC0603JRNPO9BN560
Yageo
D1
DIODE SCHOTTKY 30V 350mA SOD323
SD103BWS-TP
Micro Commerical
D2
DIODE SUPER FAST 600V 1A SMA
ES1J-LTP
Micro Commercial Co
D3, D4
DIODE SWITCH 75V 300MA SOD323
1N4148WX-TP
MICRO COMMERCIAL
D6
DIODE SUPER BARRIER 150V 2A SMA
SBR2U150SA-13
Diodes Inc
D7
DIODE SWITCH 300V 0.225A SOD123
BAV3004W-7-F
Diodes Inc
F1
RES 0.22 OHM 1/2W 5% AXIAL
NFR25H0002207JR500
Vishay BC Components
L1
10mH
RL-5480-3-10000
Renco
NTC
THERM 100K OHM ±5% 0.10mA NPb 0603
NCP18WF104J03RB
MURATA
Q1
MOSFET N-CH 600V 2.5A IPAK
AOU3N60
Alpha & Omega Semiconductor Inc
Q2
MOSFET N-CH 500V 4.3A TO251
IPU50R950CE
Infineon Technologies
Q3
MOSFET N-CH SGL 60V 360mA SOT-23
2N7002P,215
NXP
R1
RES 3.3K OHM 1W 5% METAL FILM AX
FMP100JR-52-3K3
Yageo
R2, R3
RES 750K OHM 1/8W 1% 0805 SMD
RMCF0805FT750K
Stackpole Electronics Inc
R4
RES 82 OHM 1/2W 5% CF MINI
CFM12JT82R0
Stackpole Electronics Inc
R5
RES 100 OHM 1W 5% AXIAL
PR01000101000JR500
Vishay BC Components
R6, R13
RES 47 OHM 1/10W ±1% NPb 0603
ERJ3EKF47R0V
PANASONIC
R8
RES 66.5K OHM 1/10W 1% 0603 SMD
ERJ-3EKF6652V
Panasonic Electronic Components
R9
RES 51.1K OHM 1/10W 1% 0603 SMD
ERJ-3EKF5112V
Panasonic Electronic Components
R10
RES 14k OHM 1/10W ±1% NPB 0603 FILM
CRCW060314K0FKEA
DALE
R12
RES 1.33 OHM 1/8W 1% 0805 SMD
CRCW08051R33FKEA
Vishay Dale
R14
RES 69.8k OHM 1/10W ±1% NPb 0603
CRCW060369K8FKEA
DALE
R15
RES 2.94K OHM 1/10W 1% 0603 SMD
ERJ-3EKF2941V
Panasonic Electronic Components
R16
RES 100K OHM 1/8W 5% 0805 SMD
ERJ-6GEYJ104V
Panasonic Electronic Components
TR1
EE1010
KEE
U1
CS1615
Cirrus Logic
VZ
VARISTOR 240V 1.2KA DISC 7MM
S07K150
EPCOS Inc
Z1
DIODE ZENER 500MW 16V SOD123
NZH16C,115
NXP Semiconductors
Table 1: Bill of Materials
