3. BILL OF MATERIALS
Part Description Part Number Manufacturer
C1 CAP FILM 0.12UF 250VDC RADIAL ECQ-E2124KB Panasonic Electronic Components
C2 CAP FILM 0.047UF 250VDC RADIAL B32529C3473K EPCOS Inc
C3 CAP FILM 0.1UF 250VDC RADIAL R82IC3100DQ60J Kemet
C4 CAP CER 1000PF 1KV 10% X7R 0805 102R15W102KV4E Johanson Dielectrics Inc
C5 CAP CER 0.047UF 25V 10% X7R 0603 C1608X7R1E473K TDK Corporation
C6 CAP CER 2.2UF 35V 10% X5R 0603 C1608X5R1V225K080AC TDK Corporation
C7 CAP CER 56PF 1KV 5% NP0 1206 C1206C560JDGACTU Kemet
C8 CAP ALUM 2200UF 50V 20% RADIAL ECA-1HHG222 Panasonic Electronic Components
C9 CAP CER 56PF 50V 5% NP0 0603 C1608C0G1H560J080AA TDK Corporation
C10 CAP CER 56PF 50V 5% NP0 0603 C1608C0G1H560J080AA TDK Corporation
D1 DIODE SCHOTTKY 30V 350MA SOD323 SD103BWS-TP Micro Commercial
D2 DIODE STD REC 1A 600V DO214AC GS1J-TP Micro Commercial Co
D3 RECTIFIER 1A 600V DO-41 1N4005-TP Micro Commercial
D5 DIODE SCHOTTKY 150V 3A SMB STPS3150U STMicroelectronics
D7 DIODE FAST 600V 1A SMA STTH1R06A STMicroelectronics
D8 DIODE SWITCH 100V 150MA SOD123 1N4148W-TP Micro Commercial
DB1 RECT BRIDGE GPP 600V 0.8A MBS B6S-G Comchip
L1 Renco 10mH inductor RL-5480-4-10000 Renco
NTC THERMISTOR 100K OHM NTC 0603 SMD NCP18WF104J03RB Murata
Q1 MOSFET N-CH 600V 1.3A DPAK AOD1N60 Alpha & Omega
Q3 MOSFET N-CH 600V 2.8A DPAK FQD5N60CTM Fairchild Semiconductor
Q4 MOSFET N-CH SGL 60V SOT-23 2N7002P,215 NXP
VR1 VARISTOR 175V 1200A 7MM STRAIGHT V07E175P Littelfuse Inc
R1 RES FUSIBLE WW 8.2 OHM 1W 5% FKN1WSJR-52-8R2 Yageo
R2 RES 100K OHM .5W 5% 1206 SMD CRCW1206100KJNEAHP Vishay Dale
R3 RES 82 OHM 2W 5% METAL FILM AX FMP200JR-52-82R Yageo
R6 RES 3.3K OHM 2W 5% METAL OXIDE ERG-2SJ332A Panasonic Electronic Components
R7 RES 750K OHM 1/4W 1% 1206 SMD RC1206FR-07750KL Yageo
R8 RES 750K OHM 1/4W 1% 1206 SMD RC1206FR-07750KL Yageo
R10 RES 330 OHM 2W 5% METAL FILM AX FMP200JR-52-330R Yageo
R11 RES 45.3K OHM 1/10W 1% 0603 SMD ERJ-3EKF4532V Panasonic Electronic Components
R12 RES 45.3K OHM 1/10W 1% 0603 SMD ERJ-3EKF4532V Panasonic Electronic Components
R13 RES 15.0K OHM 1/10W 1% 0603 SMD RC0603FR-0715KL Yageo
R14, R15 RES 1.80 OHM 1/4W 1% 1206 SMD CRCW12061R80FKEA Vishay Dale
R16 RES 47.0 OHM 1/10W 1% 0603 SMD RC0603FR-0747RL Yageo
R17 RES 69.8K OHM 1/10W 1% 0603 SMD RC0603FR-0769K8L Yageo
R18 RES 2.00K OHM 1/10W 1% 0603 SMD ERJ-3EKF2001V Panasonic Electronic Components
R19 RES 30.0K OHM 1/4W 1% 1206 SMD ERJ-8ENF3002V Panasonic Electronic Components
R22 RES 47.0 OHM 1/10W 1% 0603 SMD RC0603FR-0747RL Yageo
TR1 EE-20 Cirrus
U1 CS1615-PAD Cirrus
Z1 DIODE ZENER 500MW 16V SOD123 NZH16C,115 NXP Semiconductors
Z2 RES 100K OHM .5W 5% 1206 SMD CRCW1206100KJNEAHP Vishay Dale
Table 1: Bill of Materials
