AN403

11

6. DIMMER COMPATIBILITY

Lamp with a CS1616 (230V/50Hz)

Date

3/15/2013

Power Factor

1,4

0.926

Vendor

Cirrus Logic

EN55015 Compliant (Y/N)

N

Input Voltage

230V/50Hz

Nominal Input Power (W)

1,4

6.124

Form Factor

GU10

Maximum Input Power (W)

1,4

7

Model #

CRD1616-7W-28V

Output Voltage (V)

1,2

27.59V

IC

CS1616

Output Current (mA)

1,2

181

Topology

Flyback

Output Current Ripple

 120Hz (mA)

1,3

NA

Isolation (Y/N)

N

Output Power (W)

1,4

4.993

Efficiency (%)

81.5%

Dimmer

Flicker Free

Steady-State

Monotonic

Dimming

Max I

out

(mA)

Min I

out

(mA)

Manufacture

Type

# of lamps

# of lamps

# of lamps

# of lamps

1

1

1

1

Berker 2861 10

Universal

Y

Y

181

1

Bull 500W

Leading Edge

N

Y

181

2

Busch 2247U

Leading Edge

N

Y

184

1

Busch 6513U

Trailing Edge

Y

Y

180

1

Busch 6519U

Trailing Edge

Y

Y

180

1

Chint New7-6305

Leading Edge

N

Y

181

2

Chisen

Leading Edge

Y

Y

182

2

Chisen 350W

Leading Edge

Y

Y

181

1

Clipsal 32E450UDM

Universal

Y

Y

180

1

Clipsal EV51RD400

Leading Edge

N

Y

182

1

CLSEN QSY626W

Leading Edge

Y

Y

181

1

Cshyh 150W

Leading Edge

N

Y

182

2

Dbang

Leading Edge

Y

Y

181

2

Elro 1890

Twilight Sensor

Y

Y

180

0

Elro ES90W

Motion Detector

Y

Y

180

0

Futina 250W

Leading Edge

Y

Y

180

1

Leiben 450W

Leading Edge

N

Y

182

2

Lonon NB 50.OTG

Leading Edge

Y

Y

184

2

Lutron LLSI-502

Leading Edge

Y

Y

182

2

Lutron LLSM-502

Leading Edge

N

N

180

1

Merten 5725

Leading Edge

Y

Y

182

1

Merten 5771

Trailing Edge

Y

Y

130

1

MK 52471SL

Leading Edge

Y

Y

185

2
