CRD1611A-8W
DS1014RD3 5
3. BILL OF MATERIALS
Item Rev DescripƟon Qty Reference Designator MFG MFG P/N
1 DIODE RECT 400V 0.8A NPB MINIDIP 1 BR1 DIODES INC HD04-T
2 CAP 4700PF ±10% 1000V X7R NPb 1206 1 C1 MURATA GRM31BR73A472KW01L
3 CAP 0.1UF ±5% 400V MTL FLM RAD 1 C2 Panasonic ECQE4104JF
4 CAP 0.033UF ±10% 400V MTL FLM RDL 1 C3 PANASONIC ECQE4333KF
5 CAP 6.8uF ±20% 450V ELEC NPb RAD 1 C4 UNITED CHEMI-CON EKXG451ELL6R8MJ20S
6 CAP 100uF ±20% 25V EL LO ESR NPb RD 1 C5 PANASONIC EEUFM1E101
7 CAP 22UF ±20% 35V ELEC RAD 1 C6 PANASONIC EEA-GA1V220H
8 CAP 100pF ±5% 50V C0G NPb 0603 1 C7 KEMET C0603C101J5GAC
9 CAP 2.2uF ±10% 10V X7R NPb 0805 1 C8 MURATA GRM21BR71E225KA73L
10 CAP 0.33UF ±10% 50V X7R NPb 0603 1 C9 TDK C1608X7R1H334K
11 CAP 1.0uF 10% 25V X7R NPb 0603 1 C10 MURATA GRM188R71E105KA12D
12 CAP 47pF ±5% 1000V C0G NPb 1206 1 C11 JOHANSON DIELECTRICS 102R18N470JV4E
13 CAP 0.01uF ±10% 630V X7R NPb 1206 1 C12 MURATA GRM31BR72J103KW01L
14 A CAP 3300pF ±5% 50V C0G NPb 1206 1 C13 KEMET C1206C332J5GAC
15 CAP 2200PF +80/-20% 2KV CER NPb RAD 1 CY MURATA DEBE33D222ZA2B
16 DIODE FAST 600V 1A NPb DO-41 1 D1 ST STTH1R06
17 DIODE ULT FAST 600V 1A NPb SMA 1 D2 ST MICROELECTRONICS STTH1L06A
18 DIODE SKY RECT 60V 2A NPb DO-214AC 1 D3 MICRO COMMERCIAL(MCC) SS26-TP
19 DIODE SWT 75V 300mA NPb SOD323 1 D4 DIODES INC 1N4148WS-7-F
20 DIODE SWT 250V 0.4A NPb SOT-23 1 D5 DIODES INC BAV23S-7-F
21 DIODE RECT 30V 1A NPb SOD-323 2 D6 D8 DIODES INC SBR130S3-7
22 DIODE RECT 400V 1A NPb SMA 1 D7 DIODES INC S1G-13-F
23 FUSE 1A 250V TLAG NPb RAD 1 F1 LITTLE FUSE 39211000440
24 IND 4.7mH ±10% 17.6 OHM 350 DIA TH 2 L1 L2 COILCRAFT RFB0807-472L
25 XFMR 6.8mH ±10% 10 KHZ TH 1 L3 KUNSHAN EAGERNESS RM05-CL01
26 THERM 100K OHM ±5% 0.10mA NPb 0603 1 NTC MURATA NCP18WF104J03RB
27 TRAN MOSFET nCH 60V.2A NPb SOT23-3 1 Q1 DIODES INC ZVN4106FTA
28 TRAN MOSFET nCH 1.0A 600V NPb DPAK 1 Q2 ST MICROELECTRONICS STD1NK60T4
29 TRAN MOSFET nCH 0.38A 500V NPb TO-92 1 Q3 FAIRCHILD FQN1N50CTA
30 TRAN MOSFET nCH 1A 800V NPb DPAK 1 Q4 ST MICROELECTRONICS STD1NK80ZT4
31 RES 4.7k OHM 1/4W ±5% NPb 1206 FILM 2 R1 R2 DALE CRCW12064K70JNEA
32 RES 4.70K OHM 1/10W ±1% NPb 0603 1 R3 PANASONIC ERJ3EKF4701V
33 RES PWR 2.0K OHM 2W ±5% NPb AXL 1 R4 VISHAY PR02000202001JR500
34 RES 27K OHM 1/8W ±1% NPb 0805 1 R5 PANASONIC ERJ6ENF2702V
35 RES 1k OHM 2W ±5% MTL FLM NPb AXL 2 R6 R16 VISHAY PR02000201001JR500
36 RES 1.50M OHM 1/4W ±1% NPb 1206 4 R7 R8 R14 R15 PANASONIC ERJ8ENF1504V
37 RES 47 OHM 1/10W ±1% NPb 0603 3 R9 R19 R24 PANASONIC ERJ3EKF47R0V
38 RES 22.0 OHM 1/10W ±1% NPb 0603 1 R10 PANASONIC ERJ3EKF22R0V
39 RES 22.1k OHM 1/10W ±1% NPb 0603 2 R11 R17 DALE CRCW060322K1FKEA
40 RES 51.0 OHM 1/10W ±1% NPb 0603 1 R12 PANASONIC ERJ3EKF51R0V
41 RES 120K OHM 1/10W ±1% NPb 0603 1 R13 PANASONIC ERJ3EKF1203V
42 RES 14k OHM 1/10W ±1% NPB 0603 FILM 1 R18 DALE CRCW060314K0FKEA
43 RES 1k OHM 1/10W ±1% NPb 0603 FILM 1 R20 DALE CRCW06031K00FKEA
44 RES 10.5 OHM 1/4W ±1% NPb 1206 1 R21 DALE CRCW120610R5FKEA
45 RES 69.8k OHM 1/10W ±1% NPb 0603 1 R22 DALE CRCW060369K8FKEA
46 RES 5.6k OHM 1/10W ±5% NPb 0603 FILM 1 R23 DALE CRCW06035K60JNEA
47 RES 1M OHM 1/8W ±1% NPb 0805 2 R25 R26 DALE CRCW08051M00FKEA
48 XFMR 14.5mH ±10% 10 KHZ TH 1 T1 KUNSHAN EAGERNESS RM06-CL01
49 B2 IC CRUS DIM 230V LED DRV NPb SOIC16 1 U1 CIRRUS LOGIC CS1611A-FSZ/B2
50 DIODE ZENER 16V 1W NPb DO-214AC 1 Z1 MICRO COMMERCIAL SMAZ16-TP
51 DIODE TVS 300V 600W NPb DO-204AC 1 Z2 LITTELFUSE P6KE350A
Figure 2. Bill of Materials
