3. BILL OF MATERIALS
Figure 2. Bill of Materials
Item Rev Description Qty Reference Designator MFG MFG P/N
1 A WIRE 24 AWG SOLID PVC INS BLK NPb 1 A1 ALPHA WIRE COMPANY 3050/1 BK005
2 A DIODE RECT 400V 0.8A NPB MINIDIP 1 BR1 DIODES INC HD04-T
3 A CAP 0.1uF ±10% 250V POLY NPb RAD 1 C1 EPCOS B32529C3104K
4 A CAP 2.2uF ±10% 25V X7R NPb 0805 1 C2 MURATA GRM21BR71E225KA73L
5 A CAP 0.047uF ±10% 630V POLY NPb RAD 1 C3 PANASONIC ECQE6473KF
6 A CAP 0.033uF ±10% 250V POLY NPb RAD 1 C4 EPCOS B32529C3333K
7 A CAP 0.68uF ±10% 50V X7R NPb 0805 1 C5 KEMET C0805C684K5RAC
8 A CAP 22uF ±20% 450V ELEC NPb RAD 1 C6 PANASONIC-ECG EEUEB2W220
9 A CAP 100pF ±5% 50V C0G NPb 0603 1 C7 KEMET C0603C101J5GAC
10 A CAP 100uF ±20% 25V EL LO ESR NPb RD 1 C8 PANASONIC EEUFM1E101
11 A CAP 1000pF ±10% 2000V CER NPb RAD 1 C9 MURATA DEBB33D102KA2B
12 A CAP 22uF ±20% 35V ELEC NPb RAD 1 C11 PANASONIC EEA-GA1V220H
13 A CAP 4.7uF ±10% 25V X7R NPb 0805 1 C12 TDK C2012X7R1E475K
14 A CAP 0.01uF ±10% 250V POLY NPb RAD 1 C13 EPCOS B32529C3103K
15 A CAP 2200PF +80/-20% 2KV CER NPb RAD 1 C14 MURATA DEBE33D222ZA2B
16 A CAP 47pF ±5% 1000V C0G NPb 1206 1 C15 JOHANSON DIELECTRICS 102R18N470JV4E
17 A CAP 0.068uF ±10% 250V X7R NPb 1206 1 C17 KEMET C1206C683KARAC
18 A DIODE SWT 85V 215mA NPb SOT-23 1 D1 DIODES INC BAS116-7-F
19 A DIODE FAST SW 75V 350mW NPb SOD123 4 D2 D8 D9 D10 DIODES INC 1N4148W-7-F
20 A DIODE ZENER 16V 1W NPb DO-214AC 1 D3 MICRO COMMERCIAL SMAZ16-TP
21 A DIODE ULT FAST 600V 1A NPb SMA 2 D4 D6 ST MICROELECTRONICS STTH1L06A
22 A DIODE TVS 600W 250V BIDIR NPb SMBJ 1 D5 MCC SMBJP6KE250CA
23 A DIODE SKY RECT 60V 2A NPb DO-214AC 1 D7 MICRO COMMERCIAL(MCC) SS26-TP
24 A DIODE RECT 30V 1A NPb SOD-323 1 D11 DIODES INC SBR130S3-7
25 A DIODE RECT 400V 1A NPb SMA 1 D12 DIODES INC S1G-13-F
26 A FUSE 1A 250V TLAG NPb RAD 1 F1 LITTLE FUSE 39211000440
27 A CON 2POS TERM BLK 5.08mm SPR NPb RA 2 J1 J2 WEIDMULLER 1716020000
28 A HDR 1x1 ML .1"CTR S NPb GLD 6 J4 J5 J7 J8 J9 J33 SAMTEC TSW-101-07-G-S
29 A HDR 2x1 ML .1" RA GLD NPb TH 1 J6 SAMTEC TSW-102-08-G-S-RA
30 A IND 3.3mH ±10% 11.8OHM DCR NPb TH 2 L1 L2 COILCRAFT RFB0807-332L
31 A XFMR 3.1mH 10% NPb TH 1 L3 KUNSHAN EAGERNESS RM06-CL03A
32 A XFMR 1.45mH 10% NPb TH 1 L4 KUNSHAN EAGERNESS RM05-CL02A
33 A SPCR STANDOFF 4-40 THR .875L AL NPb 4 MH1 MH2 MH3 MH4 KEYSTONE 1809
34 A THERM 100K OHM ±5% 0.10mA NPb 0603 1 NTC MURATA NCP18WF104J03RB
35 A TRAN MOSFET nCH 2A 400V NPb I-PAK 1 Q1 FAIRCHILD SEMICONDUCTOR FDU3N40TU
36 A TRAN MOSFET nCH 0.38A 500V NPb TO92 1 Q2 FAIRCHILD FQN1N50CTA
37 A TRAN MOSFET nCH 1.0A 600V NPb DPAK 1 Q3 ST MICROELECTRONICS STD1NK60T4
38 A TRAN MOSFET nCH 60V.2A NPb SOT23-3 1 Q4 DIODES INC ZVN4106FTA
39 A RES 1.5k OHM 1/4W ±5% 1206 FILM 1 R1 DALE CRCW12061K50JNEA
40 A RES PWR 2.0K OHM 2W ±5% NPb AXL 2 R2 R26 VISHAY PR02000202001JR500
41 A RES 0 OHM 1/10W ±5% NPb 0603 FILM 0 R3 DALE CRCW06030000Z0EA
42 A RES 0 OHM 1/10W ±5% NPb 0603 FILM 1 R4 DALE CRCW06030000Z0EA
43 A RES 47 OHM 1/10W ±1% NPb 0603 3 R5 R27 R35 PANASONIC ERJ3EKF47R0V
44 A RES 22.1k OHM 1/10W ±1% NPb 0603 1 R6 DALE CRCW060322K1FKEA
45 A RES 4.70K OHM 1/10W ±1% NPb 0603 1 R7 PANASONIC ERJ3EKF4701V
46 A RES 2.32k OHM 1/4W ±1% 1206 FILM 1 R8 DALE CRCW12062K32FKEA
47 A RES 330 OHM 2W ±5% MTL FLM NPb AXL 3 R9 R10 R11 Panasonic - ECG ERG2SJ331
48 A RES 100k OHM 1/10W ±5% NPb 0603 FLM 2 R12 R34 DALE CRCW0603100KJNEA
49 A RES 499K OHM 1/4W ±1% NPb 1206 6 R13 R14 R15 R16 R17 R18 VISHAY TNPW1206499KFEEA
50 A RES 10.7 OHM 1/8W ±1% NPb 0805 FILM 1 R19 DALE CRCW080510R7FKEA
51 A RES 11.3 OHM 1/8W ±1% NPb 0805 1 R20 DALE CRCW080511R3FKEA
52 A RES 1k OHM 1/10W ±1% NPb 0603 FILM 1 R21 DALE CRCW06031K00FKEA
53 A RES 27K OHM 1/8W ±1% NPb 0805 1 R22 PANASONIC ERJ6ENF2702V
54 A RES 69.8k OHM 1/10W ±1% NPb 0603 1 R23 DALE CRCW060369K8FKEA
55 A RES 5.6k OHM 1/10W ±5% NPb 0603 FLM 1 R24 DALE CRCW06035K60JNEA
56 A RES 22.0 OHM 1/10W ±1% NPb 0603 1 R25 PANASONIC ERJ3EKF22R0V
57 A RES 24k OHM 1/10W ±1% NPb 0603 FILM 1 R28 DALE CRCW060324K0FKEA
58 A RES 14k OHM 1/10W ±1% NPB 0603 FILM 1 R29 DALE CRCW060314K0FKEA
59 A RES 59k OHM 1/10W ±1% NPb 0603 FILM 1 R30 DALE CRCW060359K0FKEA
60 A RES 47k OHM 1/10W ±5% NPb 0603 FILM 2 R31 R32 DALE CRCW060347K0JNEA
61 A RES 51.0 OHM 1/10W ±1% NPb 0603 1 R33 PANASONIC ERJ3EKF51R0V
62 A CON TEST PT .1" TIN PLATE WHT NPb 2 TP1 TP2 KEYSTONE 5002
63 A CON TEST PT .1"CTR TIN PLAT NPb BLK 3 TP3 TP4 TP5 KEYSTONE 5001
64 B1 IC CRUS DIMMER LED DRVR NPb SOIC16 1 U1 Cirrus Logic CS1610-FSZ/B1
65 A FUSE MOUNT TR5/TE5 3mm 2P NPb TH 1 XF1 Littelfuse 56000001319
66 A SCREW 4-40X5/16" PH MACH SS NPb 4 XMH1 XMH2MXH3 XMH4 BUILDING FASTENERS PMSSS 440 0031 PH
67 A SKT PINCH CONTACT FOR SOIC16 0 XU1 ENPLAS OTS-16-1.27-03
