Quest 110 Dual
Installation, Operation and Maintenance Instructions
6
www.QuestProtect.com
4.2B Duct Outlet (fig. 2)
Dehumidification performance can be modified by adding an outlet duct to circulate air.
4.2C Remote Area, w/Outlets Ducted (fig. 3)
A more simplified remote installation method than above uses ducting between the Quest 110 Dual
discharge and the humid room; the Quest 110 Dual inlet draws air from the room in which it’s located. This
works well if there is an adequate air flow path between the two rooms; e.g. high door undercut or wall grill.
This eliminates the need to remote mount the humidity control.
4.3 Electrical Requirements
The Quest 110 Dual plugs into a common grounded outlet on a 110-120 VAC 15-Amp circuit. While
operating, it draws less than 7.2 amps @ 80°F, 60% RH and less than 6.8 amps @ 75°F, 50% RH. Use of
a ground fault circuit interrupter (GFCI) protected circuit is recommended. The unit should not be used in
areas prone to flooding.
Input of
Humid Air
Output of
Dehumidified Air
Front View
Figure 2: Installation in humid
area with outlet ducting.
CONDITIONED SPACE
Input of
Humid Air
Output of
Dehumidified Air
Figure 3: Installation in a remote
area with ducted outlets.
