Quest 110 Dual Installation, Operation and Maintenance Instructions
4
www.QuestProtect.com
[email protected]
1. Intended Application for Quest 110 Dual
The Quest 110 Dual is intended for use in light commercial structures: however, the unit can be placed in
almost any setting where dehumidification is desired. Use in highly corrosive applications and pool areas
may void warranty.
The Quest 110 Dual works most effectively between 56° and 95°.
In order to efficiently control humidity levels, the area in which the dehumidifier is to be operated must be
free of water intrusion or excessive fresh (outside) air infiltration. Before installing the Quest 110 Dual, water
intrusion and air infiltration problems should be addressed.
2. Registrations
The Quest 110 Dual units conforms to UL STD 474 and CSA standard C22.2 No.92.
3. Specifications
4034220 Quest 110 Dual
Blower: 360 CFM @ 0.0" WG
Power: 787 Watts @ 80°F and 60% RH
Supply voltage: 115 VAC - 1 Phase - 60 Hz.
Current Draw: 7.1 Amps
Energy Factor: 2.7 L/kWh
Operating Temp: 56°F Min - 95°F Max
Minimum Performance @ 80°F and 60% RH:
Water Removal:
Efficiency:
110 Pints/Day
5.8 Pints/kWh
Air Filter: MERV-8 Size: 14" x 17.5" x 2"
Power Cord: 10’, 110-120 VAC, Ground
Drain Connection: 3/4” Threaded NPT or 5/8” Hose Barb
Dimensions:
Width:
Height:
Length:
Weight:
Unit Shipping
14.5"
19"
19.4 25"
26" 35"
85 lbs 95 lbs
