Technical Specifications
9
indicating that a cable from an external powered and fully functioning
FireWire device is connected.
5. On all TP-300FW units, connect the 12V DC power adapter to the power
socket and connect the adapter to the mains electricity.
The red ON LED lights.
6 Technical Specifications
Table 2 includes the technical specifications.
Table 2: Technical Specifications
1
of the TP-300FW FireWire Range Extender
PORT: One 6-pin serial 1394 FireWire port
2 RJ-45 twisted pair ports
TRANSFER RATE: 100Mbps
IEEE-1394 STANDARDS: IEEE 1394a-2000, IEEE 1394-1995, IEEE 1394b-2002 @ up to 100Mpbs
ESD LINE PROTECTION: IEC 61000-4-2 (ESD) 15kV (air), 8kV (contact), IEC 61000-4-5 (Lightning) 12A
(8/20us), and IEC 61000-4-4 (EFT) 40A (5/50ns)
POWER SOURCE: 12 VDC, 60mA
DIMENSIONS: 12.1cm x 7.5cm x 2.5cm (4.76" x 2.95" x 0.98") W, D, H
WEIGHT: 0.3 kg. (0.67 lbs.) approx.
ACCESSORIES: Power supply, mounting bracket
OPTIONS: RK-3T 19" rack adapter
1 Specifications are subject to change without notice
