7 technical specifications, Technical specifications – Kramer Electronics TP-330FW User Manual
Page 10
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Technical Specifications
8
7 Technical Specifications
lists the technical specifications of the TP-330FW.
Table 3: Technical Specifications
PORTS:
of the TP-330FW FireWire Range Extender/Hub
2 FireWire ports on 6-circuit FireWire 400 connectors
1 STP/UTP port on an RJ-45 connector
TRANSFER RATE:
400Mbps
IEEE-1394 STANDARDS:
IEEE 1394a-2000, IEEE 1394-1995 @ up to 400Mpbs
ESD LINE PROTECTION:
IEC 61000-4-2 (ESD) 15kV (air), 8kV (contact), IEC 61000-4-5 (Lightning) 12A (8/20us),
and IEC 61000-4-4 (EFT) 40A (5/50ns)
POWER SOURCE:
12 VDC, 60mA
DIMENSIONS:
12cm x 6.9cm x 2.4cm (4.7" x 2.7" x 0.9") W, D, H
WEIGHT:
0.4kg (0.9lbs) approx.
ACCESSORIES:
Power supply, mounting bracket
1 Specifications are subject to change without notice
