6 TP-122N - Overview
# Feature Function
1 12V DC +12V DC connector for powering the unit
2
AUDIO
OUT
S/PDIF RCA Connector Connects to the digital audio acceptor
3 ANALOG 3.5mm mini
Jack
Connects to the analog audio acceptor
4 LINE IN RJ-45 Connector Connects to the TP-121EDID or the TP-104 (that
does not accept the audio signals)
Connect via a UTP CAT 5 cable with RJ-45 connectors
at both ends (the PINOUT is defined in Section 4.1 )
5 XGA OUT 15-pin HD (F)
Connector
Connects to the XGA acceptor
6 LINK LED Illuminates when receiving the correct input signal
7 LEVEL Trimmer Adjusts the output signal level
Use a screwdriver to carefully rotate the trimmer,
adjusting the appropriate level
8 EQ. Trimmer Adjusts the cable compensation equalization level
Degradation and VGA/XGA signal loss can result from
using long cables (due to stray capacitance), sometimes
leading to a total loss of sharpness in high-resolution
signals
Use a screwdriver to carefully rotate the trimmer,
adjusting the appropriate level
9 ON LED Illuminates when receiving power
