TP-122N - Technical Specifications
5
Technical Specifications
INPUT:
1 RJ-45 LINE IN connector
OUTPUTS:
VIDEO: 1 VGA/UXGA on a 15-pin HD connector
AUDIO: 1 audio S/PDIF RCA connector; 1 audio ANALOG 3.5mm
mini jack
MAX. OUTPUT LEVEL: VIDEO: 1V; AUDIO: 2.5V
CONTROLS:
Level: –7.5dB to +4.4dB, EQ.: 0dB to +33dBm (130m) @ 50MHz
BANDWIDTH (-3dB):
AUDIO: 20Hz to 20kHz @0.5dB
For the Transmitter/Receiver pair
S/N RATIO:
VIDEO: 58dB unweighted, 68.3dB @5MHz weighted
AUDIO: <–80dB
TOTAL GAIN:
AUDIO: Analog/analog: 0dB; Analog/SPDIF: –12dBFS
COUPLING:
AC
TND+N:
AUDIO: <0.01%
POWER SOURCE:
12V DC 190mA (TP-122N)
12V DC 540mA (TP-121EDID/TP-122N pair when powered from
TP-121EDID via Power Connect)
12V DC 390mA (TP-121EDID/TP-122N pair when powered from
TP-122N via Power Connect)
DIMENSIONS:
12.1cm x 7.18cm x 2.42cm (4.76" x 2.83" x 0.95") W, D, H
WEIGHT:
0.3kg (0.67lbs) approx.
ACCESSORIES:
Power supply
OPTIONS:
RK-3T 19” rack adapter, C-GMA/GMA cable (VGA 15-pin HD (M)
+Audio jack to VGA 15-pin HD (M) +Audio jack)
Specifications are subject to change without notice
Go to our Web site
access the list of resolutions
